| Specification |
| System | operating system | linux |
| Active Users | 4 users watching online simultaneously |
| APP | OKAM PRO Overseas Edition |
| Collection | Processor | T23 |
| Memory | 512Mb |
| Image Sensor | GC2083, 200W,1/3 CMOS |
| Min illumination | 0.8Lux/F1.４ (color mode), 0.3Lux/F1.4 (black and white mode) |
| Lenses | Standard lens diameter 14mm |
| Sensor Performance | Support automatic white balance, automatic gain control, automatic backlight compensation |
| PTZ | Horizontal 305°, vertical 100° |
| Viewing Angle | D100° diagonal |
| Video | Night Vision | Full-color night vision, dual light source, 6+4 dual-color dual light sources |
| Compression Standard | H.264 /MJPEF/JPEG |
| Multi-stream | Main stream: 1296P/15fps Sub stream: 360P/15fps |
| IR Control | IR is on and the night vision function is enabled, and infrared and ICR are automatically detected; IR is off and the night vision function is disabled, infrared is always off, and ICR is fixed in day vision mode |
| Bitrate | CBR/VBR two bit rate control modes, and the output bit rate range is 128～4096kbps |
| Image Adjustment | Brightness, contrast, vertical, horizontal adjustable, OSD display |
| Audio | Enter | Built-in -38dB microphone |
| Output | Built-in 8Ω1W speaker |
| Sampling frequency | 8KHz/16bit |
| Compression standard | G711A |
| AI | Humanoid Detection | Human detection, filtering invalid event alarms |
| Area Detection | Customize monitoring area to monitor only the area that users are concerned about |
| Smart Notification | Different devices push different sounds, knowing exactly which device is triggered |
| Intelligent Alarm | Set different device alarm sounds according to different scenarios |
| More AI features | Pets, vehicles, packages, etc. |
| Network | Network Protocol | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P，IPV4, etc. |
| Wireless network | IEEE802.11b/g/n |
| Wireless frequency | 2.4~2.4835GHz |
| Wireless security encryption | 64/128-bit WEP/WPA-PSK/WPA2-PSK Data encryption |
| Wireless connectivity | AP hotspot network configuration, QR code network configuration, Bluetooth network configuration |
| Button | Button 1 | Power button |
| Reset button | Long press to restore factory settings |
| Storage | External TF card | Support T-Flash card (up to 256GB) |
| Cloud Storage | Free cloud storage, 1 day in China, 3 days abroad |
| Alarm | Sound and light alarm | Support Sound and light alarm |
| Alarm detection | Support human motion detection, PIR infrared human detection 10 meters |
| Physical Standards | Charging voltage | DC5V±5% |
| Powered by | Built-in 20000mAh battery power supply, 4*21700 |
| Power consumption | Sleep current 300uA, working: 230ma-1.5A max |
| Work Environment | Working temperature: -10～55℃, working humidity | Weight | Gross weight: TBD (Note: subject to the actual product) |
| Size | 130.5(L)×56.5(W)×88.5(H)mm |
| Packing list | Camera*1, MICRO USB*1, Manual*1, (Solar panel*1, Solar panel bracket*1 optional) |
