Vacuum Pump Portable Cow Milker Milking machine goat milker milking machine

Product Description

Product Description
Vacuum Pump Portable Cow Milker Milking machine goat milker milking machine 1.Main structure The milking machine is mainly composed of vacuum pump unit, milking device and chassis .2.Work principle The design of milking machine imitates the movement which the calf is nursed, the vacuum provides the power for the milking machine, the milk cup group is the instrument which completes milking directly. The tubbish space between the milk cup sheath is called intermural chamber, which is controlled by the connection of the short pulse tube and the pulsator3.About this machine .This machine Have two model, one is single can, the other is double cans .power 110v 220v 240v 380V..this machine can make as clients' request.Data parametersmodelNew JX vacuum pump styleMilking cup groupThe milking group number1 set pulsating frequency60-64 times/min pulsatory ratio60:40 Working Efficience10-12 cows/hourVacuum pumpmodelsplit-type pump Swept volume170L/min Operating Vacuum Degree50Kpa Method of lubricationInstil lubrication 1 ml/hElectricmotorFitted power 0.75 kw Voltage220V/380v Milk bucketVolume /piece25L Milk bucket number1 pieceMachine/setpacking measurement89x57x84cm Net weight65Kg Gross weigh80kg

---
