| US$10,000.00 | 1 Piece (MOQ) |
| Technical Parameter | |||
| Model | 4LZ-4.0E | ||
| Type | Self-propelled Whole-feeding | ||
| Dimension | Length(mm) | 4960 | |
| Width(mm) | 2890 | ||
| (Operation) | |||
| Height(mm) | 2830 | ||
| Weight(kg) | 3000 | ||
| Type | Water cool, Four-stroke, Direct Injecti | ||
| Engine | Power(HP) | 88 | |
| RPM(r/min) | 2600 | ||
| Fuel tank(L) | 130 | ||
| Gear Box | ZKB65 | ||
| HST | 40cc HST | ||
| Chassis | Track(mm) | 500*90*51 | |
| Track Center(mm) | 1150 | ||
| Ground Clearance(mm | 320 | ||
| Harvesting | Cutting Width(mm) | 2000 | |
| Feeding Capacity (kg/s | 5.0 | ||
| Cutting Bar Lift | Hydraulic Control | ||
| Threshing | Type | Axial Flow Type with Beat Bars | |
| Threshing Cylinder (m | 600*2000 | ||
| Filtrate Type | Vibrating Sieves+ Centrifugal Fan | ||
| Discharging | Grain unloading type | 360 degree rotary unloading | |
| Grain tank volume(M3 | 1.5 | ||
| Crops | Rice, Wheat, Rapessed | ||
| 4LZ-5.0E 4LZ-6.0P RUBBER TRACK COMBINE HARVESTER | ||||
| Technical Parameter | ||||
| Model | 4LZ-5.0E | 4LZ-6.0P | ||
| Type | Self-propelled Whole-feeding | Self-propelled Whole-feeding | ||
| Dimension | Length(mm) | 4960 | 5150 | |
| Width(mm) | 2890 | 2890 | ||
| (Operation) | ||||
| Height(mm) | 2830 | 3100 | ||
| Weight(kg) | 3200 | 3800 | ||
| Type | Water cool, Four-stroke, Direct Injecti | Water cool, Four-stroke, Direct Injection | ||
| Engine | Power(HP) | 98HP | 102HP | |
| RPM(r/min) | 2600 | 2600 | ||
| Fuel tank(L) | 130 | 130 | ||
| Gear Box | ZKB65 | ZKB85 | ||
| HST | 40cc HST | 45cc HST | ||
| Chassis | Track(mm) | 500*90*51 | 550*90*56 | |
| Track Center(mm) | 1150 | 1250 | ||
| Ground Clearance(mm) | 320 | 360 | ||
| Harvesting | Cutting Width(mm) | 2000 | 2200 | |
| Feeding Capacity (kg/s) | 5.0 | 6.0 | ||
| Cutting Bar Lift | Hydraulic Control | Hydraulic Control | ||
| Threshing | Type | Axial Flow Type with Beat Bars | Axial Flow Type with Beat Bars | |
| Threshing Cylinder | 600*2000 mm | 620*2000 mm | ||
| Filtrate Type | Vibrating Sieves+ Centrifugal Fan | Vibrating Sieves+ Centrifugal Fan | ||
| Discharging | Grain unloading type | 360 degree rotary unloading | 360 degree rotary unloading | |
| Grain tank volum | 1.5 M3 | 1.6 M3 | ||
| Crops | Rice, Wheat, Rapeseed, Soybean | Rice, Wheat, Rapeseed, Soybean, Corn | ||
