| Technical Parameters | | | | | ||||
| Item | | | Standard Value | Maximum Value | ||||
| Processing Capacity | Maximum bar material through-hole diameter | | 46mm | - | ||||
| | Maximum granule diameter (disc type) | | 300mm | 350mm | ||||
| | Maximum processing work piece length | | 210mm | 230mm | ||||
| | Stainless steel single side cutting amount | | 2mm | 5mm | ||||
| | Work piece applicable machining accuracy | | ±0.01mm | - | ||||
| | Machined surface smooth finish | | 1Ra | 1.6Ra | ||||
| | Tool rest center height | | 40mm | - | ||||
| | Machine tool turning diameter | | 350mm | - | ||||
| | Square knife specifications | | 16*16mm | - | ||||
| Travel | X axis effective travel (diameter) | | 700mm | - | ||||
| | Z axis effective travel | | 230mm | - | ||||
| Feed | X axis fast moving speed | | 20m/min | 30m/min | ||||
| | Z axis fast moving speed | | 20m/min | 30m/min | ||||
| | X axis servo power | | 1.5KW | - | ||||
| | Z axis servo power | | 1.5KW | - | ||||
| Spindle | Maximum spindle speed | | 3500rpm | 4000rpm | ||||
| | Spindle motor power | | 5.5KW | 7.5KW | ||||
| | Spindle nose model | | A2-5 | - | ||||
| | Hydraulic chuck available dimensions | | 8 inches | 10 inches | ||||
| Size & Weight | External dimensions | | Estimated 2100*1500*1900mm | - | ||||
| | Overall weight / Net weight | | Estimated 2600KGs | - | ||||
| Machine Tool Specifications and Component Items | | Specifications | Standard Configuration | Optional Configuration | ||||
| Component Specifications | Lead screw | 25mm | Taiwan ball grinding precision grade | - | ||||
| | Guide rail | 25mm | Taiwan H-class linear guide rail | - | ||||
| | Axle bearing | - | Self developed high rigidity gun barrel spindle | | ||||
| | Spindle motor | 3.7KW | 3.7KW servo spindle | - | ||||
| | Feed servo | 1.5KW | Yashu & DMC invent joint developed high speed servo | - | ||||
| | Numerical control system | 820Ti | NANJINGKT | - | ||||
| Machine Tool Specifications | Lathe bed form | 45 degrees | Slanting bed lathe | - | ||||
| | Base form | - | Heavy duty anti deformation patented base | - | ||||
| | Clamping method | - | Hydraulic clamping | - | ||||
| Optional Devices for the Machine | Fly cutter / End face or side face 2 live tooling / End face or side face 3 live tooling / Side face 4 live tooling on the Y Axis / Y Axis 4+4 live tooling / Servo turret / Oil bar feeder | | | | ||||
| * Tips: The above configuration parameters are for reference only and are subject to the listed configurations and physical acceptance based on the price composition. | | | | | ||||
