| US$22.00-23.60 | 200 Pieces (MOQ) |
| MODEL | TG003A-30W-DB | TG003A-50W-DB | TG003A-100W-DB | TG003A-150W-DB | TG003A-200W-DB | TG003A-300W-DB | TG003A-400W-DB |
| POWER | 30W | 50W | 100W | 150W | 200W | 300W | 400W |
| LED QTY | 36PCS-6V-2835SMD | 72PCS-6V-2835SMD | 144PCS-6V-2835SMD | 216PCS-6V-2835SMD | 288PCS-6V-2835SMD | 360PCS-6V-2835SMD | 504PCS-6V-2835SMD |
| Luminous Flux | 3000-3300LM | 100-110LM/W | 100-110LM/W | 100-110LM/W | 100-110LM/W | 100-110LM/W | 100-110LM/W |
| Input Voltage | DOB AC100-265V | DOB AC100-265V | DOB AC100-265V | DOB AC100-265V | DOB AC100-265V | DOB AC100-265V | DOB AC100-265V |
| Withstand Voltage | 1500V | 1500V | 1500V | 1500V | 1500V | 1500V | 1500V |
| Anti-surge | 1.5KV | 3.5KV | 3.5KV | 3.5KV | 3.5KV | 3.5KV | 3.5KV |
| Power Factor | >0.5 | >0.5 | >0.5 | >0.5 | >0.5 | >0.5 | >0.5 |
| Color Rendering Index | >80 | >80 | >80 | >80 | >80 | >80 | >80 |
| Color Temperature | 3000-6500K | 3000-6500K | 3000-6500K | 3000-6500K | 3000-6500K | 3000-6500K | 3000-6500K |
| IP Rating | IP66 | IP66 | IP66 | IP66 | IP66 | IP66 | IP66 |
| Beam Angle | 90° | 90° | 90° | 90° | 90° | 90° | 90° |
| Housing Color | Black/Grey | Black/Grey | Black/Grey | Black/Grey | Black/Grey | Black/Grey | Black/Grey |
| Working Temp | -30ºC~50ºC | -30ºC~50ºC | -30ºC~50ºC | -30ºC~50ºC | -30ºC~50ºC | -30ºC~50ºC | -30ºC~50ºC |
| Humidity | 10%~95%RH | 10%~95%RH | 10%~95%RH | 10%~95%RH | 10%~95%RH | 10%~95%RH | 10%~95%RH |
| Body Material | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy |
| Life Time | >30000Hrs | >30000Hrs | >30000Hrs | >30000Hrs | >30000Hrs | >30000Hrs | >30000Hrs |
| Warranty | 2 Years | 2 Years | 2 Years | 2 Years | 2 Years | 2 Years | 2 Years |
| Dimension L*W*D(mm) | 155*125*25 | 210*160*25 | 270*208*25 | 335*250*33 | 380*282*33 | 455*328*35 | 485*368*35 |
| Net Weight(kg) | 0.3 | 0.48 | 0.8 | 1.4 | 1.8 | 2.5 | 3.2 |
