| US$20.00-25.00 | 50 Pieces (MOQ) |
| Electrical Specifications | |
| FreqRange | 2400-2500/5150-5850MHz |
| Gain | 10±1dBi |
| Horizontal Beamwidth | 90±5º |
| Vertical Beamwidth | 30±5º |
| S11 | ≤1.8@2400-2500MHz,≤1.5@5150-5850MHz |
| Impedance | 50Ω |
| Polarization | V Pol |
| Max. Power | 50W |
| Connector | N-type straight female (dual port) |
| Lightning Protection | DC ground |
| Mechanical Specifications | |
| Dimension | 255x255x40mm |
| Pole size | Φ40-Φ50mm |
| Weight | 153g |
| Rated Wind Velocity | 36.9m/s |
| Operational Humidity | <95% |
| Operating temperature | -40~55ºC |
| Radome material | ABS(white) |
