China Made High Quality Pure Titanium Ta1 Pipe Fitting Pipe Tube

Product Description

Product Description
Good Quality Titanium Alloy Pipe
1. Products Introduction

Item Name	Titanium foil / strip
Type	GR1, GR2, GR3, GR4, GR5, 6AL4V Eli, GR7, GR9, GR12, GR23,TB3, TB6, TC4, TC6, TC11, TC17, TC18
Standard	ASTM B265, AMS4911, AMS4911H, GB/T3621-2007
Specification	0.025-0.5mm Thickness 50-700mm width
Certificate	ISO 9001:2008
Supply Ability	100 Tons per Month
Delivery	Within 5~30 days

2. Chemical Composition

Grade	N	C	H	Fe	O	Al	V	Pa	Mo	Ni	Ti
Gr1	0.03	0.08	0.015	0.2	0.18	/	/	/	/	/	bal
Gr2	0.03	0.08	0.015	0.3	0.25	/	/	/	/	/	bal
Gr3	0.05	0.08	0.015	0.3	0.35	/	/	/	/	/	bal
Gr4	0.05	0.08	0.015	0.5	0.4	/	/	/	/	/
Gr5	0.05	0.08	0.015	0.4	0.2	5.5~6.75	3.5~4.5	/	/	/	bal
Gr7	0.03	0.08	0.015	0.3	0.25	/	/	0.12~0.25	/	/	bal
Gr9	0.03	0.08	0.015	0.25	0.15	2.5~3.5	2.0~3.0	/	/	/	bal
Gr12	0.03	0.08	0.015	0.3	0.25	/	/	/	0.2~0.4	0.6~0.9	bal

3. Tensile Requirements

Grade	Tensile strength(min)		Yield Strength(min)		Elongation(%)
	ksi	MPa	ksi	MPa
Gr1	35	240	20	138	24
Gr2	50	345	40	275	20
Gr3	65	450	55	380	18
Gr4	80	550	70	483	15
Gr5	130	895	120	828	10
Gr7	50	345	40	275	20
Gr9	90	620	70	438	15
Gr12	70	438	50	345	18

4. Contact us Shanghai Bozhong Metal Group Co., Ltd.
ADD: 5F, Building #32, No.518 Xinzhuan Rd, Songjiang District, Shanghai, P.R.China 201612
Contact: Mr. Paik








Website: https://shanghaibozhong.en.made-in-china.com

---
