Laser Bridge CNC Type Stone Cutting Machine for Granite

US$15,000.00
1-4 set
US$14,900.00
5+ set

Basic Info.

Model NO.
QZQ-1600
Automation
Manual
Precision
Precision
Application
Ceramics, Cement Brick, Concrete Curb, Granite, Marble
Type for Grinding Machine
Special Grinding Machine
Grinding Machine Type
Vibration Polishing Machine
Grinding Method
Wet Grind
Certification
ISO, CE
Condition
New
Main Motor Power
15kw
Max Cutting Size
3000*1200*450
Cutting Table Rotation
0-90degree
Blade Diameter
900-1200
Transport Package
1set Machine in One 20 Gp Container
Specification
5000*2200*2400mm
Trademark
wanlong
Origin
Fujian Quanzhou
HS Code
8464101000
Production Capacity
180sets/Month

Product Description


Laser Bridge CNC Type Stone Cutting Machine for Granite
QZQ-600/1200 Bridge Type Edge Cutting machine(medium size)equipped with 360 degree rotary table adopts wide-span bridge type structure. Horizontal stone slicing can be achieved by moving the girder. The maximum blade vertical stroke can be up to 3.6M with flexibility in rotation, recise in positioning, and stability in operation. Themainframe of the machine adopts imported frequency transducer to achieve stepless adjustment of cutting speed. It is applicable for cutting valuable tombstones.Technical parameters QZQ-600/128
Max. Diameter of blade mm 600-1200Blade vertical stroke 500Cutting tabletation range n 0-360°Water consumption 4Main motor power kw 18.5Table dimension (L*W) mm 3000*1600Overall dimension (L*W*H) mm 6300*4500*3200Max cutting dimensions (L*W*H) mm 3200*2000*450Approximate weight. Kg. 6500

QZQ-900 QZQ-1200
Max. diameter of blade mm 600-900 1000-1200
Main motor power KW 18.5 18.5
Blade vertical stroke mm 500 500
Table dimensions(L x W) mm 3000*2000 3000*2000
Cutting table rotation range n° 0-360° 0-360°
Max. cutting size(L x W x H) mm 3000*1600*300 3000*1600*450
Overall dimensions(L x W x H) mm 6000*5000*4200 6000*5000*4200
Water consumption m³/h 4 4
Approximate weight Kg 6000 6500
