Factory Hook Lift Garbage Truck Roll-off 10tons Hook Lifting Compression Waste Truck Hooklift Garbage Truck for Sale

Product Description

Hook Lift Garbage Truck Roll-off 10tons Hook Lifting Compression Waste Truck
Specifications
(1) HOWO 6x4 Hook Lift Garbage Compactor truck
(2) 6x4 LHD/RHD Driving model for choosing
(3) Horse Power:266-420HP
(4) Euro II emission
(5) Certification: ISO9001 CCC,SGS
hook lift garbage truck for sale is also called hook arm garbage truck, mainly used in transporting kinds garbage for municipal sanitation department,large factories and mines ,etc, especially apply to transport the household waste in residential area. This truck can be equipped with many detachable garbage bin, use conveniently.
Technical Specifications of hook lift garbage truck

Cabin	HW76 Standard Cab, Left hand drive, one sleeper. A/C With two bunks, 70° hydraulically tillable to the front as attached photo for ref. (picture just for reference)
Vehicle Main Dimensions	(L x W x H)mm		10120x2500x3370
	Wheel base (mm)		4325+1350
	Wheel track (front/rear) (mm)		2022/1830
	Approach/Departure angle(°)		16/23
Weight in KGS	Tare Weight			12950
	Loading Capacity			15000
	Front axles loading capacity			HF9 1x8000
	Rear axles loading capacity			2*ST16 1x16000
Max. driving speed(km/h)					75
Engine		Brand		Sinotruk
		Model		WD615.69
		Type		4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
		Horse Power(HP)		336HP
		Emission standard		Euro 2
Gearbox		HW19710, 10 Forwards gear & 2 reverse
Clutch		Reinforced diaphragm clutch, diameter 430mm
Steering Gear		ZF 8098, power steering, hydraulic steering with power assistance
Fuel tank (L)		300
Tire		12R22.5 radial steel tire 10 Pieces with one spare
Brakes		Service brake: dual circuit compressed air brake Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake
Paint		Anti-corrasive
Garbage box body		Box size: 6000*2300*1500mm Floor thickness: 8mm; Wall side thickness: 4mm. Reinforced with strengthen cross. A complete set of hydraulic system: Chinese famous brand. Garbage box with 2 pieces tarpaulins, 14 hooks to attach tarpaulins

FAQ of hook lift garbage truck:

.Q:Trading or Factory?
AXiagong Chusheng (Hubei) Special Purpose Vehicle Manufacturing Co., Ltd.., is one factory for special vehciles in China
2. Q:Factory Location?
A:We are located in Suizhou City, Hubei Province, China, covering nearly 80,000 square meters, with own office builing, canteen, workshop, tesing square,etc.
3.Q:Visit there?
A:You will be welcomed here for factory inspection here, you could take Plane to the capital city airport, and we will meet you there, or take Train here directly, we will meet you at the train station.
4.Q: Ability?
A:We have experienced engineer and skillful team workers here for your vehicle.
5.Q:Production time & stock?
A:Please find us that we could check for you the order arrangement here, and instant stock condition.
More Pictures for Garbage Truck
Packing & shipping
Nude and wax, shipped in bulk cargo ship, flat deck or RO-RO
(1)Wax:
Do wax spray process to against the trailer body suffer seawater corrosion during shipping
(2)Package:
Stable fixing with steel wire,to protect the trailer during shipping
(3)Shipping:
Reliable logistic service from famous freight supplier makes transport process safely and promptly


Certification

Customer visiting

Our Service
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
Other Products we sell
Comany information
1. Xiagong Chusheng (Hubei) Special-purpose Vehicle Manufacturing Co., Ltd. is a famous and the biggest manufacturer with very professional experience in special automobile field for more than 15 years in China. We have more than 3000 workers, 400 technicians, and factory scale is more than 690,000m2.
2. Our most advantage and leading products including LPG tanker series, Water Tank, Fuel tank, Refrigerated Truck, Garbage Truck, Towing/Wrecker truck, Dump Truck, Sewage Suction Truck, Concrete Mixer Truck, Bulk Cement Truck, Van Truck, Sweeper Truck, Truck with Crane, Fire fighting Truck, High-altitude Operation Truck, Chemical Liquid Truck, Milk Transport Truck, LED Display Truck, Various Semi-trailer, Spare parts etc.
3. We have successfully exported to more than 60 countries, such as Ghana, Togo, Sudan, Kuwait, Peru, Nigeria, Benin, Angola, Tajikstan, Azerbaijan, Namibia, Burma, Korea, Iran, Afghanistan, Iraq, Philippines, Vietnam, Saudi Arabia, Mexico, Chile, Bolivia, Tanzania, Zambia, Zimbabwe, Yemen etc.
** We have strict quality control of raw material, professional management team and technical workers, advanced equipments, strict inspection before delivery, excellent packing and shipping team.

---
