| Model | DG12000SE |
| Frequency[Hz] | 50 60 |
| Voltageg[V] | 110/220.115/230.120/240 |
| Rated Power( KW) | 9 9.5 |
| Max. Power(KW) | 10 10.5 |
| Rated Output Current（A ) | 39.1 41.3 |
| DC Output | 12V 8.3A |
| Phase | Single phase |
| Excitation Method | Brush self-excitation |
| Power FactorΦ | 1.0(0.8) |
| Insulation Class | F |
| Fuel Tank Capaciity[L] | 25 |
| Engine Model | 2V80 |
| Start Method | Electric Start |
| Engine Type | two cylinders,V-type,water-cooled, vertical |
| Bore*Strokke[mm] | 2-80 * 79 |
| Displacement | 0.794 |
| Compression Ratio | 23 ; 1 |
| Speed[rpm] | 3000 3600 |
| Power [Kw] | 12 13 |
| Oil Capacity[L] | 2.2 |
| Fuel Consumption[g/kwh] | ≤290 ≤297 |
| Fuel No. | Diesel: 0#(Sumner), -10#(Winter) Use No. 0 diesel in summer, and use No. -10 or No. -20 diesel in winter. |
| Oil No. | SAE10W30 (CD grade or above) uses CD or above grade 15W-40 oil (or SAE equivalent grade oil) |
| Optional | ATS,Remote Control,Intelligent digital display panel |
| Size [mm] (L*W*H) | 1400*650*820 |
| Packing Size [mm] (L*W*H) | 1500*750*920 |
| Net Weight/Gross Weight[Kg] | 310/330 |
