Conventional Turret type Milling machine 58"X12" large working table Taiwan spindle, OEM

Product Description

Conventional Large table Milling machine
Table size: 1470*320mm (58" * 12") X axis travel 1000mm, Y/Z axis travel 400mm which is much longer than standard M4VB; our casting is double layer, with square guide way, this improves the casting's rigidity, and the square guide way could keep entire machine more stable during processing metal pieces, also ensure the precision when the knee moving up and down; Y axis is square guide way, its load-bearing and guiding performance are much better than dovetail; After enlarge the table size to 1470*320mm, we also make the saddle and knee larger accordingly, the cross and vertical guide way are full covered, so when move the table to one side end, it well prevents entire machine to overturn, and keep the working precision better.
and here is the specification:

Model	M4VLW
	Precision High Accuracy Series
Table size(L*W)(mm)	1470x320
Max.load of table (kg)	300
X axis(mm)	1000 920 with power feed
Y axis(mm)	400
Z axis (mm)	400
Work table T slot (No.-size*pitch) (mm)	3-15.88x65
Distance between spindle and table(mm)	50-450
Ram travel (mm)	520
Travel of spindle quill (mm)	127
Auto crossward feed(mm/rev)	0.04/0.08/0.15
Spindle speed(rpm)(60Hz)	80-5440 rpm 16steps
Spindle hole taper	R8 / ISO30 / ISO40 (optional )
Main Motor	3HP
Tilt angle for milling head	left and right±90º forward and backward±45º
Guiding tracks(X.Y.Z)	X axis dovetail, Y&Z axis square guideway
Dimension(L*W*H)(mm)	1950x1670x2150
Milling head	Round step milling head
Weight (kg)	1400

Pictures for reference only:

---
