High-Efficiency DC Motor Gear Reducer for Industrial Applications

Product Description

Product Feature

Applicable industries	Suitable for conveying and sorting light cargo in various distribution centers, logistics centers, and automatic production logistics lines.
Safe voltage	Both DC24V & 48V are safe voltages. No risk of electric shock. Safe and applicable.
Ultra high torque	The energy conversion efficiency from input to output is high. Depending on the type, the torque efficiency is more than 10 times higher compared to AC drums with the same outer diameter.
Speed control	Simple speed adjustment through a dedicated control card
Precise braking position	Standard electromagnetic brake and brake point recovery servo brake mechanical brake can be selected.
Fixed speed conveying	Regardless of the weight of the transported goods, constant speed transportation is achieved through signal feedback.
ZPA transfer (accumulation function)	ZPA conveying can be easily achieved through a dedicated control card without the need for control program settings.
Easy and quick installation	Compared to traditional external reduction motor, electric roller is simpler and faster to install on the conveying equipment, requiring only 1/4 of the installation time of the traditional external reduction motor system.
Safety in use	The electric roller integrates the motor, reduction device and other components into a sealed cylinder. Only the support shafts at both ends need to be fastened to the conveying equipment, making the equipment operation safer and more reliable.

Detailed Photos

Product Parameters
Static Load Capacity (Unit: KG)

Diameter (mm)	Length (mm)
	300	400	500	600	700	800	900	1000	1100	1200	1300
Φ50mm	80	70	60	55	50	45	40	35
Φ60mm	140	140	110	110	80	80	60	60	45	30	20

Performance parameter
Pipe diameter Φ50mm, rated power: 50W, maximum power 90W

Speed code	Gearbox	Gear ratio	Linear velocity		Roller speed (prm)		Torque (N.m)		Tangential force (N)		Current (A)
		K	min	max	min	max	rated	start-up	rated	start-up	rated	start-up
A6	Level 3	139	1	6	7	39	18.6	101	745	4023.2	24V/5A 48V/2.4A	24V/10A 48V/4.8A
A7		115	1	7	9	47	15.4	83	616.4	3328.6
A8		100	2	8	10	54	13.4	72	536	2894.4
A9		95	2	9	11	57	12.7	69	509.2	2749.7
A11		79	2	11	13	68	10.6	57	423.4	2286.6
A12		71	2	12	14	76	9.5	51	380.6	2055
A13		68	2	12	15	79	9.1	49	364	2002
A14		59	3	14	17	92	8	43	320	1760
A15		51	3	17	20	106	6.8	37	272	1496
A30	Level 2	27	6	31	37	200	4.16	22	166.4	915.2
A35		22	7	39	45	245	3.39	18	135.6	745.8
A40		19	8	45	53	284	2.92	16	116.8	642.4
A50		16	10	53	63	338	2.46	13	98.4	541.2
A60		14	11	61	71	386	2.15	12	86	473
A160	Level 1	5.2	30	163	192	1038	0.72	4	28.8	158.4
A190		4.3	37	197	233	1256	0.6	3	24	132
A230		3.7	42	229	270	1459	0.52	3	20.8	114.4

Pipe diameter Φ50mm, rated power: 80W, maximum power 160W

Speed code	Gearbox	Gear ratio	Linear velocity		Roller speed (prm)		Torque (N.m)		Tangential force (N)		Current (A)
		K	min	max	min	max	rated	start-up	rated	start-up	rated	start-up
B6	Level 3	139	1	6	7	39	18.6	101	745	4023.2	24V/5A 48V/2.4A	24V/10A 48V/4.8A
B7		115	1	7	9	47	15.4	83	616.4	3328.6
B8		100	2	8	10	54	13.4	72	536	2894.4
B9		95	2	9	11	57	12.7	69	509.2	2749.7
B11		79	2	11	13	68	10.6	57	423.4	2286.6
B12		71	2	12	14	76	9.5	51	380.6	2055
B13		68	2	12	15	79	9.1	49	364	2002
B14		59	3	14	17	92	8	43	320	1760
B15		51	3	17	20	106	6.8	37	272	1496
B30	Level 2	27	6	31	37	200	4.16	22	166.4	915.2
B35		22	7	39	45	245	3.39	18	135.6	745.8
B40		19	8	45	53	284	2.92	16	116.8	642.4
B50		16	10	53	63	338	2.46	13	98.4	541.2
B60		14	11	61	71	386	2.15	12	86	473
B160	Level 1	5.2	30	163	192	1038	0.72	4	28.8	158.4
B190		4.3	37	197	233	1256	0.6	3	24	132
B230		3.7	42	229	270	1459	0.52	3	20.8	114.4
