| US$150,000.00-300,000.00 | 1 Piece (MOQ) |
| roject | specifications | TC-400 |
process capability | Maximum turning diameter | 400mm |
| maximum machining diameter | 280mm | |
| maximum machining length | 350mm | |
| travel stroke | X-axis travel | 180mm |
| Z-axis travel | 350mm | |
| feed | X/Z direction of the screw rod | X3210, Z3210 |
| X/Z guide rail | 35 roller guide rail | |
| Precision parameters | X, Z repeatability precision | 0.003-0.005mm |
| X, Z positioning accuracy | 0.003-0.005mm | |
| lathe bed | The tank is a one-piece frame structure | Japanese high and low rail 30° |
| Main shaft unit | maximum speed | 3500(rpm) |
| Through-hole diameter | 52mm | |
| Axial end form | A2-5/6 | |
| Recommended power | 5.5-7.5KW | |
| Magnetic ring encoder | Tenda / Bally | |
| Tail unit | Top sleeve diameter | 80mm |
| Top taper | MT-5 | |
| Top gear has a maximum travel | 100mm | |
| Tail position form | Steel guide | |
| size | Put on the approximate size of the whole machine | 2000*1450*1650mm |
| weight | Pure optical weight | 1650kg |
