| US$9,000.00-25,000.00 | 1 Set (MOQ) |
| Series/Model | 0.75L series | PM-6 | PM-6E | PM-9E | PMG-7 | PMG-9 |
| Technical parameter | Maximum bottle volume | 0.75L | 0.75L | 0.75L | 0.75L | 0.75L |
| Maximum bottle diameter | Φ68 | Φ68 | Φ68 | Φ72 | Φ72 | |
| Maximum bottle height | 245mm | 245mm | 240mm | 250mm | 230mm | |
| Heating unit | 4 | 4 | 6 | 6 | 8 | |
| Design output rate(bph) | 6600bph | 9600bph | 12000bph | 14000bph | 18000bph | |
| Number of molds | 6 | 6 | 9 | 7 | 9 | |
| Service power(kw/h) | 24-36 | 30-50 | 40-60 | 30-60 | 45-60 | |
| Installation power(kw) | 70 | 75 | 110 | 110 | 128 | |
| HP air consumption (m3/min) | 4 | 6 | 8 | 7 | 10 | |
| | LP air consumption(m3/min) | 3 | 2 | 2 | / | / |
| Weight (T) | 6.5 | 7.5 | 9.5 | 8 | 10 | |
| Dimension(M) | 4.1*2.3*2.3 | 4.5*2.4*2.3 | 5.6*2.6*2.4 | 7.0*2.2*2.9 | 5.7*2.2*2.7 | |
| | ||||||
| Bottle preform holder made by high accurancy CNC, to guarrantee the long-term use and stable movement on the cycle of pet preform | Heating lamp Apply with high quality Infrared lamp, to guarrantee the long-term use and low cost to do manintenance |
| Servo stretching mold The servo stretching speed is fast and the position is precise. When adjusting the stretching height, only the data of the motor needs to be adjusted, without the need for manual adjustment of the machine hardware | Blowing mold The mold is made by 7075 Aluminum material, fast cooling cycle, so the bottle is shaped beautiful,highly polished,Good transparency, light mold weight, easy to change mold. |
| Standardized electrical design Professional engineer design all electrical components, and apply high quality imported and local brands, to guarrantee the stable performance of our machines | Independent control box whole movement is controled on the PLC on control box, easy to use and do adjustment the machine. impove the efficiency. |
