Rubber Track Conveyor Transport Transfer Transmit Shot Blast Machine Vehicle Belt

Product Description

FINEYEAR Special rubber and Plastics
An industrialized entity that integrates scientific research, development, production, and operation

Qingdao FINEYEAR Rubber & Plastic Co., Ltd. is located in the beautiful coastal city of Qingdao west coast, is a collection of scientific research, development, production, installation, commissioning services and sales as one of the shot blasting machine, shot blasting machine track and shot blasting machine accessories production enterprises. From 2015 to 2020, it has been rated as A Grade A taxpayer by the State Administration of Taxation for six consecutive years [3]. The company adopts a strict management model, has a rich industry experience of the staff, engineers, with a good scientific research foundation, experimental conditions and production base. [1] The main products of the company are: shot blasting machine track, road shot blasting machine, crawler shot blasting machine, hook shot blasting machine, through shot blasting machine, catenary shot blasting machine, drum shot blasting machine, rotary table shot blasting machine, wire shot blasting machine, road shot blasting machine, drum shot blasting machine, mesh belt shot blasting machine and shot blasting machine accessories, At the same time, the company also produces sand treatment equipment, environmental dust removal equipment and mechanical parts, which provide reliable and important equipment for casting, forging, heat treatment, steel structure, container, machinery, shipbuilding, aircraft, locomotive and other industries at home and abroad.
Qingdao FINEYEAR Rubber & Plastic Co., Ltd. has been engaged in the production of shot blasting machine and shot blasting machine rubber track for more than 20 years, with advanced production technology, perfect testing means, scientific management system. The company has independent land and independent property rights of the factory, the company has established a technology research and development center and has a perfect quality management system, all products using SolidWorks and CAD/CAM computer-aided design and manufacturing, product appearance using three-dimensional solid design, key components using finite element numerical simulation analysis, rotating parts through dynamic balance test. Strictly ensure product quality.
Rubber products production workshop 4500 square meters, has an independent rubber testing laboratory, equipped with advanced test equipment and testing personnel, product quality is guaranteed; The company has 5 rubber track production lines, with 1730 four-roll calender, no need for external processing, product autonomy.

At present, there are many manufacturers producing shot blasting machines at home and abroad, please pay attention to whether the track you choose matches the equipment model when installing or replacing the track. In the case of confirming the matching with the equipment, the installation of the track first pay attention to the running direction on the track.
When installing and debugging, first gently pull the adjustment bolts on both sides, especially some tracks without guiding edges are easy to run off, first let the track idling for 1 to 2 hours, and then pull properly according to the load of the equipment.
Track shot blasting machine has a wide range of applications, please first consider whether the equipment is suitable for your product or pay attention to avoid scratches between the workpiece and the track when selecting the equipment.
The following problems with the track are not quality problems:
1, the shot blasting machine hit or adjust improper deviation, wear uneven;
2, with burr workpiece scratches or scratches the track; Long, sharp workpiece inserted into the track hole to cut the track; The workpiece is stuck by the guard plate, door fan, etc., and breaks the track;
3, the workpiece installed too little can not completely cover the track, steel sand directly hit the track to break the track;
4. The weight of a single piece of work exceeds 15 kg, or the total weight of the work exceeds the equipment load, Q326 200 kg, Q3210 500 kg;
5. The track is not tensioned or overweight after being used for a long time, causing the active roll to wear the track.

Model number	perimeter	wide	thick	aperture	KG load	Guide edge
Q326	3300	1100	17	6	200	None/yes
Q326	3300	1100	17	10	200	None/yes
Q326A	3400	1130	17	4and7	200	None/yes
Q326B	3300	1130	17	4and7	200	None/yes
Q326C	3300	1100	17	4and7	200	None/yes
Q326D	3400	1130	17	6and10	200	None/yes
Q326E	3400	1130	17	6and10	200	None/yes
Q326F	3400	1130	17	4	200	None/yes
Q3210	4900	1400	20	13	500	None/yes
Q3210A	4900	1400	20	13	500	None/yes
Q3210B	4900	1400	20	13	500	None/yes
6GN-5R	3710	1130	19	7	200	None/yes
SBS-100	3300	1000	17	6	200	None/yes
SBS-100	3300	990	17	6	200	None/yes
SBS-100	3300	960	17	6	200	None/yes
SBS-100	3300	800	17	6	200	None/yes
SNB-30	4450	1150	20	6and9	300	None/yes

---
