Recycled Wine / Whisky / Vodka Small Glass Bottle Remove Label Washing Machine

Product Description

Product Description
Recycled Wine / Whisky / Vodka Small Glass Bottle Remove Label Washing Machine
Product Description
Machine description:
Main structure and working principle
This machine consists of soaking machine , outside brushing machine, inside brushing machine,transmission system and electrical control box.
The bottle is cleaning as the follows:
Feeding empty bottle--soaking and spraying--external brushing--internal brushing-- bottle inside water spraying--drying and bottle out
Among: the temperature of hot alkaline water is 50-55℃, the concentration of alkaline is about 2.5%.
Main structure and working principle of soak machine
The soak machine consists of main transmission mechanism, control bottle mechanism, roller drum, soaking pool.
Main transmission mechanism
After reduction, the power motor can be divided into two ways: one route intermittent motion mechanism drives the drum part to make intermittent rotation; one route and two pairs of cone gears engage to drive the bottle control mechanism to rotate.
Machine show:
Oil-fired steam boiler
Company information
Workshop detail
Our team
Our exhibition
Project cases
FAQ
Q1: How to find reused glass bottle washing machine ?
A1: Looking for glass bottle washing machine in www.grandeemachine.en.china.cn
Q2: Which kinds of glass bottle washing machine we have?
A2: 2000 bottles per hour or 5000-6000 bottles per hour
Q3: How to confirm the bottle shapes, label materials for washing machine ?
A3: Confirm the glass bottle is round shape with bottle sizes from 200ml to 1000ml, bottle
Height is not more than 110mm, bottle diameter is not more than 340mm. Label material should be wet glue paper, sticky label is also no proble for our washing machine.
Q4: Which other extra equipment need for this washing machine?
A4: Oil fried boiler will be required to generate steam to remove the labels
Q5: Are you a trading company or a manufacturer?
A5: We are the manufacturer of water / beverage filling machine and water treatment system over 10 years.We just not only sell drinking water machines and other related equipment , Quality is our culture. We have rich experienced engineers with technicians working team , providing good and after-sales service , professional salesman team .
Q6: Do you have technical support after we purchased your machines?
A6: We will arrange our professional technical to go aboard to your factory, they will help you and teach you how to install and maintenance the machines which you purchased. Or help you to fix machine when it has problems.
Q7: If you buy our machines, can you offer us wear-out spare parts?
A7: We provide our high quality machine 2 years guarantee , and we will also offer you 2 years wear-out spare parts for free. Once your machines broken or doesn't work within 2 years and you can't solve it, firstly, we will try to help you to find problems from your words description by phone or other communication tolls. Secondly, if the phone solutions still not work, our engineers will go to your factory to solve it. Meanwhile, they will teach you the related experiences for fixing.

---
