Automatic Paraffin Heating Granulating Machine/Paraffin Forming Machine /Paraffin Melting Machine

Product Description

Product Description
Automatic paraffin heating granulating machine/Paraffin forming machine /Paraffin melting machine
Through the specific mechanical structure and working principle, the paraffin wax after a series of treatment, the formation of uniform size, regular shape of the particles, through the screw or plunger and other devices to extrude the paraffin through the mold with a specific aperture, the paraffin wax at the exit of the mold is extruded into strips, and then through the cutting knife to cut it into uniform particles. Just like making noodles, the dough (like paraffin) is first extruded into strips through a mold, and then cut into small segments (pellets).
Major component
Heating system: Used to heat the solid paraffin wax to a liquid state for subsequent molding operations.
Molding system: If extrusion molding, including screw, barrel and mold. The screw is used to push the paraffin forward in the barrel and apply pressure, the barrel plays the role of holding the paraffin and working with the screw, and the mold determines the shape and size of the particles.
Cooling system: After the paraffin particles are formed, they need to be cooled in time to shape them.
Cutting system (for extrusion molding) : consisting of a cutter and a power unit, the cutter speed and cutting timing need to be precisely controlled to ensure uniform particle length. The power device is generally a motor, which drives the cutter to work through the transmission device.
Application scenario
Candle manufacturing/Industrial packaging/Chemical raw material processing.
Product Parameters

specification	Minor	1000mm×600mm×1200mm
	middle	2000mm×1000mm×1800mm
	large	5000mm×2000mm×3000mm
weight	Minor	200-500kg
	middle	1-3t
	large	>10t
Dynamic system	Motor power	1.5kw-30kw
	Rotational speed	1400r/min 2800r/min
	Transmission mode	Belt/gear/chain drive
Heating system	Minor	3-8kw
	middle	10-20kw
	large	30-60kw
	temperature	50 degrees Celsius -150 degrees Celsius
Cooling system	Motor power	0.3-3kw
	Air cooling system	5-10min
	Water cooling system	2-8min
Productive capacity	Minor	10-50kg/h
	middle	100-500kg/h
	large	1000kg/h
Particle size	1-10mm

Company Profile
Dongguang Tiancheng Machinery Factory, located in Chengnan Development Zone, Dongguang County, Cangzhou City, Hebei Province, 50 meters away from National Highway 105, 3 kilometers away from Beijing-Taiwan Highway,
The traffic is very convenient, the factory covers an area of 20 acres, construction area of 5000 square, with perfect cold and hot processing capabilities, the existing various precision processing equipment 30 sets, with a variety of precision machining capabilities, the existing staff of more than 40 people, including 6 engineering and technical personnel, advanced production equipment, perfect testing means, in petrochemical machinery has a good reputation, Well received by users.
The main products of our factory are: a complete set of benzol dewaxing refining equipment and technology, casing crystallizer, plate wax forming machine, particle forming machine, tower granulation, scraper forming machine, rotary condensing granulator and so on. The company has obtained a number of national patents, products sold at home and abroad and a number of large and medium-sized petrochemical enterprises.
Our factory will, as always, adhere to the "customer first, quality first, reputation first, service first" business purpose, strive to pursue excellence, and create brilliant results, welcome new and old customers to visit the company guidance exchange.
