Psr Series Soft Starter Psr37-600-70 1sfa896110r7000 10070091

Product Description

Description:
The softstarter PSR37-600-70 has a rated maximum operational current of 37 A with an operating voltage span from 208...600 V AC. The rated control voltage is between 100...240 V AC at 50/60 Hz. PSR features a two-phase control soft start and stop through a voltage ramp. It has built-in bypass for easy installation and energy saving. A RUN and a TOR signal is available from a relay output in NO (normally open state). The start/stop ramp and time is easy to set by three potentiometers on the front. PSR is often used in combination with a manual motor starter (MMS) from ABB, so mechanical connection kits are available. Another popular option is Fieldbus communication, which can be enabled by an external adaptor and a Fieldbus plug. The PSR range is our most compact softstarters with basic functionality and values. They are suitable for small three-phase motors with nominal currents from 3...105 A and can manage up to 100 starts per hour. Common applications are, for example, pumps, fans, compressors, and conveyors.

Rated operational voltage Ue,208…600 VAC,Rated control supply voltage,Us,100…240VAC,50/60 Hz
EC rated			current	UL/CSA rated					Type	Order code	Net	Net
operational power				operational power							Welght	Welght
230V	400V	500V	le	200/208V	220/240V	440/480V	550/600V	FLA			(kg)	Ib
Pe	Pe	Pe	A	Pe	Pe	Pe	Pe
kW	kW	kW		hp	hp	hp	hp
0.75	1.5	2.2	3.9	0.5	0.75	2	2	3.4	PSR3-600-70	1SFA896103R7000	0.4	0.8
0.5	3	4	6.8	1	1.5	3	5	6.1	PSR6-600-70	15FA896104R7000	0.4	0.8
2.2	4	4	9	2	2	5	7.5	9	PSR9-600-70	15FA896105R7000	0.4	0.8
3	5.5	5.5	12	3	3	7.5	10	11	PSR12-600-70	15FA896106R7000	0.4	0.8
4	7.5	7.5	16	3	5	10	10	15.2	PSR16-600-70	1SFA896107R7000	0.4	0.8
5.5	11	15	25	7.5	7.5	15	20	24.2	PSR25-600-70	1SFAB96108R7000	0.6	1.3
7.5	15	18.5	30	7.5	10	20	25	28	PSR30-600-70	1SFA896109R7000	0.6	1.3
7.5	18.5	22	37	10	10	25	30	34	PSR37-600-70	1SFA896110R7000	1	2.2
1	22	30	45	15	15	30	40	46.2	PSR45-600-70	1SFA896111R7000	1	2.2
5	30	37	60	20	20	40	50	59.4	PSR60-600-70	1SFA896112R7000	2.1	4.6
22	37	45	72	20	25	50	60	68	PSR72-600-70	1SFAB96113R7000	2.1	4.6
22	45	55	85	25	30	60	75	80	PSRB5-600-70	1SFA896114R7000	2.1	4.6
30	55	55	105	30	40	75	100	104	PSR105-600-70	1SFA896115R7000	2.1	4.6
Rated operatlonalvoltage Ug,208..600 VAC,Rated control supply voltage,Ug,24VAC/DC,50/60 Hz
IEC rated			current	UL/CSA ated					Type	Order code	Net	Net
operational power				operational power							Welght	Welght
230V	400V	500v	le	200/208V	220/240V	440/480V	550/600V	FLA			(kg)	(ib)
Pe	Pe	Pe	A	Pe	Pe	Pe	Pe
kW	kW	kW		hg	hp	hg	hg
0.75	1.5	2.2	3.9	0.5	0.75	2	2	3.4	PSR3-600-11	1SFA896103R1100	0.4	0.8
0.5	3	4	6.8	1	1.5	3	5	6.1	PSR6-600-11	1SFA896104R1100	0.4	0.8
2.2	4	4	9	2	2	5	7.5	9	PSR9-600-11	1SFA896105R1100	0.4	0.8
3	5.5	5.5	12	3	3	7.5	10	11	PSR12-600-11	1SFA896106R1100	0.4	0.8
4	7.5	75	16	3	5	10	10	15.2	PSR16-600-11	15FA896107R1100	0.4	0.8
5.5	11	15	25	7.5	7.5	15	20	24.2	PSR25-600-11	1SFA896108R1100	0.6	1.3
75	15	18.5	30	7.5	10	20	25	28	PSR30-600-11	1SFA896109R1100	0.6	1.3
7.5	18.5	22	37	10	10	25	30	34	PSR37-600-11	1SFA896110R1100	1	2.2
1	22	30	45	15	15	30	40	46.2	PSR45-600-11	1SFA896111R1100	1	2.2
5	30	37	60	20	20	40	50	59.4	PSR60-600-11	15FA896112R1100	2.1	4.6
22	37	45	72	20	25	50	60	68	PSR72-600-11	1SFA896113R1100	2.1	4.6
22	45	55	85	25	30	60	75	80	PSR85-600-11	15FA896114R1100	2.1	4.6
30	55	55	105	30	40	75	100	104	PSR105-600-11	1SFA896115R1100	2.1	4.6
