Wind Generator Turbine 150kw 200kw 300kw, Wind Power Mill for Industrial and Home Use, Customized Available

Product Description

Wind Turbine 150KW 200KW 300KW, Wind Power Generator for Industrial and Home Use
We Can accept customized wind Mill Generator Manufacturing
Product features:
1. Ultrasonic anemometer
The conventional mechanical anemometer has simple structure; the internal rotating parts have wear loss, are easy to be lost by wind and sand, and are easy to be disturbed by freezing, rain and snow. The new ultrasonic anemometer has no mechanical friction loss, small and compact structure, low external influence and high reliability. It is used to accurately detect real-time wind conditions.
2. Solar aviation indicator
Instead of traditional indicator light, there is no need to connect to external power supply to save installation space. The device is composed of silicon solar panel and multi-layer LED light source. The high-efficiency silicon solar physical panel provides large capacity maintenance free battery power storage, and provides electric energy for the flasher to flash at night.
3. Stainless steel ball lightning rod
SUS304 stainless steel is used as a whole, with corrosion resistance, beautiful shape, simple structure and convenient installation. It can be used for direct lightning protection with wide protection angle and strong wind resistance.
4. Intelligent automatic fire extinguishing material integrated sticker
This product is an innovative invention in the fire industry. It is a set of simple and highly reliable independent automatic fire extinguishing device. No power supply, no special smoke and temperature sensing controller, no responsible equipment and pipelines. Just paste it inside the equipment, you can accurately and effectively detect and extinguish the source of goods and nip the disaster in the initial stage.
5. Automatic grease filler
Instead of the traditional step of manually adding grease to the bearing, it is automatically controlled by the program to add butter to the bearing parts on time and accurately.
Technical parameter:

Model Model	XTL-DLK-100KW	XTL-DLK-200KW	XTL-DLK-300KW
Rated power	100kW	200kW	300kW
maximum power	110kW	220kW	330kW
Rated voltage	360V	360V	360V
Starting wind speed	2.5m/s	2.5m/s	2.5m/s
Rated wind speed	10m/s	10m/s	10m/s
Safe wind speed	45m/s	45m/s	45m/s
Net weight of main engine	1500KG	1650KG	1800KG
Diameter of wind turbine	22m	26m	28m
Blade height	10.5m	12.5m	13.5m
Number of blades	3slice
Blade material	Reinforced FRP
Body material	High quality alloy steel
Generator	Three phase AC permanent magnet generator
Control System	Electronic yaw protection
Yaw Mode	Electronically controlled yaw upwind
Lubrication mode	Self lubrication
Tower form	Independent tower
Working temperature	-40ºC~80ºC

---
