Auto Feed Drilling Machine Z5025A Z5030A Z5032A Z5035A Z5040A Z5050A

US$2,500.00-4,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

Z5025A Z5030A Z5032A Z5035A Z5040A Z5050A

Structure

Vertical Drilling Machine

Layout

Vertical

Controlling Mode

Artificial

Number of Shaft

Hole Diameter

<50mm

Automatic Grade

Manual

Precision

Certification

CE, ISO 9001

Condition

New

Max. Driiling Capacity

30mm

Max. Taping Capacity

M18

Max.Spindel Travel

135mm

Spindle Bore Taper

Morse 3

Spindel Speed

70-2600rpm

Column Diameter

125mm

Motor Power

1.1/1.5kw

Transport Package

Plywood Case

Specification

Cast Iron

Trademark

HOYONG-TRD

Origin

Shandong, China

HS Code

845929000

Production Capacity

300

Product Description

Vertical Drilling Machine Features:
The machine is designed with multi-function of drilling. Broaching, reaming, tapping and facing milling.
With a strengthened capacity of drilling it allows the workpieces to be drilled with larger range of size.
It is suitable for using in both production and maintenance shops
1. Easy operation.
2. Casting iron structure for long durability.
3. Column type of vertical drilling machine.
4. Worktable can tilt 45degree
function of drilling. Broaching, reaming, tapping and facing milling.
With a strengthened capacity of drilling it allows the workpieces to be drilled with larger range of size.
It is suitable for using in both production and maintenance shops
1. Easy operation.
2. Casting iron structure for long durability.
3. Column type of vertical drilling machine.
4. Worktable can tilt 45degree
SPECIFICATIONS:

MODEL		Z5030A	Z5035A	Z5040A	Z5050A
Max. drilling capacity(mm)		30	35	40	50
Max. taping capacity(mm)		M18	M20	M24	M24
Distance from spindle axis to generating line of column(mm)		315	330	360	360
Max. distance from spindle nose to work table surface(mm)		520	610	600	600
Max. distance from spindle nose to base(mm)		1080	1150	1215	1205
Max. spindle travel(mm)		135	150	180	180
Max. adjustment of work table and table rest(mm)		480	540	560	525
Swivel of table and table reat		±45°	±45°	±45°	±45°
Spindle bore taper(Morse)		3	4	4	4
Spindle steps		12	12	12	12
Spindle speed(r/min)		70-2600	70-2600	42-2050	42-1685
Spindle feed steps		3	3	4	4
Spindle feed range(mm/r)		0.1,0.2,0.3	0.1,0.2,0.3	0.07,0.15, 0.26,0.4	0.07,0.15, 0.26,0.4
Column diameter		125	140	160	170
Effective area of table(mm)		450x450	500x550	580x450	580x450
Effective area of base plate(mm)		690x480	760x500	820x550	820x550
Dimension of T-slot (mm)		2-14 2-16	2-14 2-16	2-14 2-16	2-14 2-16
3-phase tea-speed AC motor	Power(kW)	1.1/1.5	1.5/2.2	2.2/2.8	2.2/2.8
3-phase pump motor	Power(kW)	0.09	0.09	0.09	0.09
Packing size(mm)		650x1050x1950	700x1150x2150	700x1150x2150	700x1150x2150
