Top-Suspended Automatic Scraper Discharge Centrifuge, Automatic Batch Sugar Centrifuge

Product Description

Top-suspended Automatic Scraper Discharge Centrifuge

Introduction Centrifuge XJZ is kind of fully automatic centrifuge with top suspended mechanical scraper discharge. It is used to separate sugar and honey under the action of centrifugal force field, and the sugar material is scraped off the drum wall through the radial and axial movements of the scraper to complete the unloading process. The machine is equipped with water washing and steam washing devices, which can fully wash materials.
Application :1. The machine is equipped with water washing and steam washing devices, which can fully wash materials and meet the needs of sugar production process.
2. This machine is widely used for separating honey from glucose paste and is a key equipment in the glucose industry.
3. This machine can also be used to separate materials with fine solid grains, high viscosity, good fluidity, tight texture and difficult to discharge by gravity. Generally, the solid-liquid ratio (weight ratio) of suspension is 40~60%.
4. The machine has good performance and the following features:
(1) AC variable frequency drive is adopted. In the periodic automatic cycle operation, the variable frequency stepless speed regulation can meet the requirements of low speed feeding, high speed separation, low speed unloading, etc. to the maximum extent. According to the change of material performance, the corresponding rotating speed point can be provided to achieve optimal operation.
(2)Programmable logic controller (PLC) is used for electrical control. The 10 inch color touch screen can set the time of each process and display the real-time working status of each process. It is flexible, simple and convenient to operate.
The whole machine is jointly controlled by electrical, pneumatic and mechanical equipment to realize full automatic cycle operation of each process.
(3) The parts in contact with materials shall be made of austenitic stainless steel, so as to ensure the cleanness of sugar and paste separation.
The overall structure is compact and the operation is stable.
4) Large capacity, high speed, high separation efficiency, large production capacity, high degree of automation, low noise, and low labor intensity.
Machine structure

Product Parameters
Technical Parameters

Model		XJZ 1350-N	XJZ1450-N	XJZ1600-N	XJZ 1700-N
1	Dia of basket mm	1350	1450	1560	1600
2	Height of basket mm	1025	1170	1170	1220
2	Max.Speed mm	1450	1200	1100	1050
3	Max.load capacity kg	1250	1300	1750	2200
4	Working volume liter	797	870	1089	1370
5	G.force	1590	1007	1083	1048
6	Power of motor kw	90 to 250	110	200	250
7	Size mm	2756*1846*4466	2508*1900*5364	3120*2290*4920	3190*2190*4780
8	Weight kg	6200	8600	10000	12000

Special tips:
1. The technical parameters shall be subject to the product specification.
2. During the inquiry, the customer shall inform the material characteristic parameters and working conditions in detail.
3. According to the special needs of customers, we can adopt personalized design and manufacturing:
4. Material: the material of the material contact part can be ordinary stainless steel, special stainless steel or titanium alloy.
5. Motor type: ordinary or explosion-proof single speed motor can be used.
6. Filter screen clearance width selection range: 0.02-0.4mm.
7. It can be designed and manufactured according to GMP specifications.
8. Other technical requirements can be negotiated.
