| No. | item | Parameter(all is subject to our final design) |
1
| Suitable raw material | Type | Common galvanized & pre-painted steel |
| Yield strength | 235MPa(or other high strength steel) |
| Thickness(mm) | 0.4-0.7 |
| width(mm) | According to final design |
| 2 | Manual uncoiler's capacity | Max.5tons |
| 3 | Forming speed(m/min) | About 18-20m/min |
| 4 | Main motor power(KW) | 7.5kw |
| 5 | Hydraulic power(KW) | 3kw |
| 6 | Forming roller groups | Around19-20 groups |
| 7 | Raw material of forming roller | High quality No.45 steel |
| 8 | Raw material of cutting blade | Cr12mould steel with quenched treatment |
| 9 | controlling system | Mitsubishi PLC& converter |
| 10 | Suitable industrial voltage | According to your special requirement |
| 11 | Machine dimensions(L*W*H) | 6.8m×1.8m×1.52m |
| 12 | Machine weight | About 9-10tons |
