SM-150T Small Model European Design Servo Energy Saving Injection Molding Machine

Product Description

Product Description: Introducing the SM-150T Horizontal Small Automatic Servo Energy Saving Plastic Pet Bottle Preform PVC Tubes Servo European Design Injection Molding Machine. This preform injection machine is perfect for producing plastic products with precision and efficiency. With its advanced servo technology, it ensures energy savings while delivering high-quality results. Trust K&E Machinery for reliable installation, debugging, and after-sales service. Warranty: 12 months for the machine and 6 months for easy broken parts.
Parameters:

SPECIFICATION		SM-150
SCREW TYPE		A	B	C
Injection Unit
Screw diameter	mm	38	42	45
Screw L/D ratio	L/D	24.3	22	20.5
Shot volume(theoretical)	CM3	227	277	318
Injection weight(PS)	g	206	252	289
Injection rate	g/s	100	122	140
Injection pressure	Bar	2127	1741	1517
Screw speed	rpm	230
Clamping Unit
Clamping force	KN	1500
Open stroke	mm	380
Space between tie-bars(W*H)	mm	470*420
Max mould height	mm	500
Min mould height	mm	160
Ejector stroke	mm	120
Ejector force	KN	50
Others
Max pump pressure	Bar	16
Motor pump power	Kw	18.2
Heating power	Kw	7.9
Machine dimension(L*W*H)	M	4.66*1.27*1.65
Oil tank cubage	L	250
Machine weight	Ton	4.5

Product Description: K&E Machinery (Ningbo) Co., Ltd. presents the Sm-150t Horizontal Small Automatic Servo Energy Saving Plastic Pet Bottle Preform PVC Tubes Servo European Design Injection Molding Machine. This injection molding machine is perfect for producing plastic products, with a focus on preform injection. It offers excellent after-sales service, including engineer installation and debugging. The machine comes with a 12-month warranty, with easy broken parts covered for 6 months. Experience the benefits of servo technology and energy-saving design with this high-quality injection molding machine.

Items		Brand/country
Servo System	Controller	TECHMATION -8' (TAIWAN )
	Servo Motor	INOVANCE (CHINA)
	Servo Drive	INOVANCE (CHINA)
	Oil Pump	ECKERLE (Germany) or SUMITOMO (JAPAN )
Electric Unit	Stroke transducer	NOVO or FLTCH (Germany)
	Breaker	Schneider (France ) or LS (Korea )
	Contactor	Schneider (France ) or LS (Korea )
	Air Switch	Schneider (France )
	Location /Speed Sensor	Schneider (France )
Hydraulic Unit	Hydraulic Direction Valve	YUKEN (Japan)
	Proportion back-pressure valve	North man (Taiwan)
	Plasticizing hydraulic Motor	DAN DUN (ITALY)
	Hydraulic Hose	MANULI(ITALY) or GOOD YEAR (USA)
	Hydraulic Sealing ring	All Italy and Japan
Others Unit	Mechanical safety	Standard
	Electric safety	Standard
	Mold close fast	Standard
	Injection Unit	Linear guide-way
	Air core	1pcs
	Hydraulic Core	1pcs
	T slots and screw holes	Standard
Servo system Compared with the other manufacturers is big, Overload ability strong and stable.

---
