Basic Info.
Application
Square, Highway, Garden
Certification
CCC, CE, Energy Star, FCC, PSE, REACH, RoHS, VDE
With Light Source
With Light Source
LED Chips Brand
Bridgelux
Height
3m, 4m, 5m, 6m, 7m, 8m, 9m, 10m, 11m, 12m
Metal Protection
Hot Dipped Galvanized
Transport Package
Bulk Packing
Production Capacity
1000 Sets/Week
Packaging & Delivery
Package Size
820.00cm * 50.00cm * 50.00cm
Package Gross Weight
100.000kg
Product Description
Product Description
CE/RoHS 100W Solar Street Lights
MW driver 30W 60W 90W LED Street Lighting prices of street light LED 100W 120W 150W
Power: 30W-60W, 70W-200W LED street lighting
Pole height: 5M, 6M, 8M, 9M, 10M, 12M
Other light sources: MH lamp, HPS lamp, HID lamp available
LED Driver: MW driver Street Light LED
LED Brand: CREE/BRIDGELUX LED street lighting
We Are Manufacturer
We manufacture led street lighting from 10W-280W since 1998
We manufacture street lighting poles from 3M-12M for LED lighting
We are capable to produce 10000 LED street lights per month
Features of our LED Street Lighting
The heat sink is designed outside in the air to dissipate heat quickly
Anodized aluminum alloy surface without painting, good for heat dissipation
Special reflector enlarges the beam angel to 120 degree
Longer pole space available, less poles required to save project cost
Individual LEDs: 1W LED with 1 heat sink, fast heat dissipation makes it 50,000 hours long life time
All-in-one structure, waterproof and dustproof LED street lighting
Light fixture itself is a large heat sink, fast heat dissipation
Specifications
| Input Voltage | AC 110V~270V 50Hz |
| LED Wattage and quantity | 30-200pcs |
| LED brand | CREE/BRIDGELUX led street lighting |
| Luminous Flux | 2930- 16100lumens |
| Light Fixture Efficiency | >90 lm/W |
| Power Factor | 90% |
| Color temperature | 5000~6500k |
| Color Rendering Index | More than 75 |
| Suggested Mounting Height | 3 ~ 12 m Street Light LED |
| Working Temperature | -30°C~ 50°C |
| Working Humidity | 10%~90% |
| Materials | Aluminum and toughened glass |
| Lamp Arm Adaptor | Diameter 48-60mm |
Life Span
| 50, 000 hours |
| IP Rate | IP65 |
BAODE 50-150W LED Street Light 120W solar led CE ROHS IP65
Item name
| 120W COB LED Street light
|
Replace
| 225w HPS or Metal Halide
|
Power
| 120W
|
Voltage
| DC30-36V ,AC85-265V
|
Beam angle
| 120 degree
|
LED quantity
| 1pcs
|
LED chip brand
| USA Bridgelux 45mil G1
|
Led driver brand
| Meanwell or Beeqoo
|
Lumen output
| 12000lm
|
Dimension
| 90*335*880mm
|
Weight
| 4.02kgs
|
Color temperature
| 2700-7000k
|
CRI
| >70
|
Power factor
| >0.95
|
Waterproof
| IP65
|
Install pole
| Φ60
|
Material
| Die + Photoelectric Glass
|
Working Environment Temp
| -40°C~50°C
|
Warranty
| 3 years
|
Certificates
| CE,ROHS
|
Applications
| LED Street Lighting | LED Road Lighting |
| LED Driving way Lighting | LED Highway Lighting |
| LED Parking Lot Lighting | LED Freeway Lighting |
| LED Avenue Lighting | LED Retrofit Lighting |
| LED Park Light | LED Gate Light |
Company Information
21 Years Manufacturing Experience
Since 1998, we have started manufacturing street lighting. The 21 years' experiences have been a persuasive insurance for us to offer reliable products.
Large Factory with Complete Facility
We have 400 staffs with factory area 6000 m2. We also equipped with complete production and testing equipments, such as Steel Pole Rolling Machine, Spray Machine, Pressure Machine, Integrating Sphere, Lighting Simulating Machine and Weather-ability Testing Machines, etc . .
Our 60 experienced engineering team work with the PV institute of Shanghai FUDAN University , Shenzhen Foxconn to R&D outdoor lighting products. We have obtained over 20 national patents and built our own brand LUYOU.
Manufacturing main components to save cost. BAODE manufactures the solar panel, light fixture and pole to control the cost and quality.
Factory outlet. There's no middleman between the manufacturer BAODE and domestic and oversea buyers.
>>
