Hebei Dongjie Wire Mesh Products Co., Ltd. is a private scienceand technology enterprise in Hebei Provience, mainly engaged in the production and sales of air filteration and separation products, and filtration and separation products, and fluid contamination control and filtration products.
Since its establishment, the company has always stuck to the mission of "honest man and careful work" and continuously explored the market, upgrate the devices, reformed technologies, get rid of the stale and bring forth the new, and strive for customers' satisfaction. With sophisticated technical experts, professional devices, and manufacture technologies, we firmly believe that we can meet your requirements.
Concept:
cartridge filter is mainly used for removal of general sand filter can remove the tiny suspended particles and colloidal substances, such as purification of drinking water.
| Specifications |
| Product Name | Anping Dongjie reverse osmosis systems stainless steel oil filter element
| |
| Product Type | reverse osmosis systems oil filter |
| Brand | Dongjie |
| Material | 304, 304 l, 304, 316 l stainless steel woven mesh, mesh, welded wire mesh, copper mesh, aluminum net, etc. |
| Sizes | 5-40 inches( as your request) |
| Filter Fineness | 1-200 um |
| Working Temp | 0.1-30 MPa |
| Samples | By free, within 5 days |
| OEM | Welcome |
TYPE : PF-D/L-R , PF- Filter Element, D-Diameter, L-Length, R-Resolution
TYPE
| L(mm)
| D(mm)
| M
| Filter area
| R (μm)
| Material
|
PF-86/200-R
| 200
| 86
| M65x2P
| 0.20M2
| 3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75
| stainless steel fiber felt, Stainless steel woven mesh
|
PF-86/350-R
| 350
| 0.35M2
|
PF-86/500-R
| 500
| 0.50M2
|
PF-100/800-R
| 800
| 100
| M80x2P
| 1.00M2
|
| TYPE
| L
(mm)
| D
(mm)
| M
| Filter area
| R(μm)
| Material
|
PF-65/250-R
| 250
| 65
| 226
223
220
215
| 0.135M2
| 3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75
| stainless steel fiber felt, Stainless steel woven mesh
|
PF-65/500-R
| 500
| 0.38M2
|
PF-70/750-R
| 750
| 70
| 0.42M2
|
PF-70/750-R
| 750
| 70
| 0.60M2
|
|
| |
TYPE
| L
(mm)
| D
(mm)
| M
| Filter area
| R(μm)
| Material
|
PF-35/102-R
| 102
| 35
| M18
M20x2.5
M20x1.5
NPT1"
3/4-16
| 0.026M2
| 3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75
| stainless steel fiber felt, Stainless steel woven mesh
|
PF-35/207-R
| 207
| 0.07M2
|
PF-35/210-R
| 210
| 0.07M2
|
PF-35/242-R
| 242
| 0.08M2
|
PF-35/425-R
| 425
| 0.15M2
|
PF-35/485-R
| 485
| 0.20M2
|
| TYPE
| L
(mm)
| D
(mm)
| M
| Filter area
| R(μm)
| Material
|
PF-62/180-R
| 180
| 62
| G1"
| 0.09M2
| 3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75
| stainless steel fiber felt, Stainless steel woven mesh
|
PF-86/254-R
| 254
| 86
| G2"
| 0.17M2
|
PF-86/381-R
| 381
| 0.20M2
|
PF-86/508-R
| 508
| 0.27M2
|
PF-86/760-R
| 760
| 0.58M2
|
PF-140/760-R
| 760
| 140
| 0.65M2
|
|
| |
TYPE
| L
(mm)
| D
(mm)
| M
| Filter area
| R(μm)
| Material
|
PF-60/1432-R
| 1432
| 60
| 2"x12UN-2A
| 1.015M2
| 3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75
| stainless steel fiber felt, Stainless steel woven mesh
|
PF-60/1241-R
| 1241
| 0.98M2
|
PF-60/1025-R
| 1025
| 0.81M2
|
| TYPE
| L
(mm)
| D
(mm)
| M
| Filter area
| R(μm)
| Material
|
PF-60/400-R
| 400
| 60
| M33x1.5P
M33x2P
| 0.40M2
| 3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75
| stainless steel fiber felt, Stainless steel woven mesh
|
PF-60/500-R
| 500
| 0.50M2
|
PF-60/1000-R
| 1000
| 1.00M2
|
|
| |
1.High dirt holding capacity, high filtering accuracy, longer on stream life.
2.Corrosion resistance of nitric acid, alkali, and organic solvent proof.It can be used for a long period of service in the temperature of 600 degree.
3.High porosity and excellent permeability which results in low pressure drop and large flow.
4.Pleatable, provide a large filter area, and can be welded and machined.
5.Cleanable, can be for used many times.
1. Polyester melt purification in chemical fiber and membrane industries.
2. High temperature filtration and corrosion liqiud filtration in petroleum industry.
3. Hydraulic fuel and lubrication oil filtration in mechanical equipment.
4. Liquid purification in pharmaceutical, biological and beverage industries.
Package:
Inner package: carton;
Outer package: wooden case;
Goods could also be packaged as customer requirement.
Delivery: Xingang, Tianjin Port
15-20 days
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
>>
