| Rated Power (kVA/kW)* | 250 kVA/250 kW | 300 kVA/300 kW | 400 kVA/400 kW | 500 kVA/500 kW | 600 kVA/600 kW |
| Input |
| nput voltage (V) | 380/400/415V(3-phase +Neutral +PE) |
| Frequency (Hz) | 40-70 Hz |
| nput power factor | >0.99 |
| THD | <3% |
| Input voltage range | 323-477V |
| Dual mains inpu | Yes (default:single mains input) |
| Outpu |
| Parallel | Up to 5 UPSs for capacity (or 5+1 for redundancy) |
| Nominal output voltage (V) | 380/400/415V |
| Efficiency:Double conversion mode | Up to 96% |
| ECO mode | 99% |
| Overload capacity in normal operation | 150%for 1 minute,125%for 10 minutes,105%continuous |
| Output voltage tolerance | +/-1% |
| Load Power Factor compatibility | From 0.5 leading to 0.5 lagging |
| Communication and management |
| Communication interface | RS485,dry contacts,Ethernet (SNMP,Modbus,TCP/IP,BACnet) |
| Control panel | 7-inch touchscreen LCD,status,and display console |
| Weights and dimensions |
| UPS,unpackaged/dimensions (H × W × D) | 1970x600x850mm | 1970x1000x850 mm |
| UPS,unpackaged weight | 425 kg | 465 kg 560 kg | 640kg | 720 k |
| Raalatop, |
| Safety | EC/EN 62040-1 |
| EMC | EC/EN 62040-2 |
| Performance | EC/EN 62040-3 |
| Markin | CE |
| Raitery tyee |
| Battery type | VRLA |
| Number of batteries | 36-50 |
Charging power in %of output power
(selectable) | 26% | 24% |
| Environmental |
| Relative humidity | 0 to 95%non-condensing |
| Operating elevation | 0 to 1500 m without derating |
| Audible noise at 1m from unit | 70db | 72db |
| Protection class | IP20 (IP31 with optional kit) |
| |
