Basic Info.
Processing Accessory
Chuck CNC Lathe
Certification
GS, CE, RoHS, ISO 9001
Swing Over Cross Slide
90mm
Taper of Spindle Bore
Mt1
Face Milling Capacity
25mm
End Milling Capacity
10mm
Transport Package
Plywood Case
Specification
520*300*410mm
Production Capacity
200units/Month
Packaging & Delivery
Package Size
58.00cm * 34.00cm * 46.00cm
Package Gross Weight
36.000kg
Product Description
Product description:
Technical parameter :
Technical parameter :
| SPECIFICATION | MP125 |
| Lathe | |
| Swing over bed | 125mm |
| Swing over cross slide | 90mm |
| Distance between centers | 180mm |
| Taper of spindle bore | MT1# |
| Spindle bore | 9mm |
| Spindle speed | 560-2500rpm |
| Metric threading | 10/0.25-1.0mm |
| Inch threading | 21/22-64tpi |
| Worktable size | 85x60mm |
| Travel of cross slide | 80mm |
| Travel of compound slide | 35mm |
| Tailstock quill travel | 20mm |
| Taper of tailstock quill | MT1# |
| Motor power | 120W |
| Milling/Drilling | |
| Drilling capacity | 15mm |
| End milling capacity | 10mm |
| Face milling capacity | 25mm |
| Spindle speed | 500-2500rpm |
| Spindle taper | MT1 |
| Spindle stroke | 40mm |
| Spindle nose to table | 120-180mm |
| Head rotary | 360° |
| Machine weight | 48kg |
| Packing Size | 520x300x410mm |
Standard accessories:
| DESCRIPTION | SPECIFICATION | QTY |
| Dead Center | MT 1# | 2 |
| Arbor | MT 1# B10 + M6 Threading | 1 |
| Drilling Chuck | MT 1# 0 - 6mm B10 Arbor | 1 |
| Change Gear | Z:25 | 1 |
| Change Gear | Z:30 | 1 |
| Change Gear | Z:34 | 1 |
| Change Gear | Z:35 | 1 |
| Change Gear | Z:36 | 1 |
| Change Gear | Z:40 | 1 |
| Change Gear | Z:45 | 1 |
| Change Gear | Z:50 | 1 |
| Milling Head Cover | ABS | 1 |
| Draw Bar | | 1 |
| Chuck Cover | PMME | 1 |
| Straight Driver | | 1 |
| Cross Driver | | 1 |
| Allen Wrench | 3, 4, 5 | 1 |
| Double Wrench | 8 - 10mm | 1 |
| Chuck Key | 80mm Three-Jaw Chuck | 2 |
| Oil Can | 50ML | 1 |
Optional accessories:
| Specification |
| 100mm 4-Jaw Independent chuck |
| Carbide Cuuting Tools 10x10 (9PCS / BOX) |
| Machine vise 50mm |
| End milling cutter (2, 3, 4, 5, 6mm) |
| Wood cutting braket |
| Center for wood |
Company information:
FAQ
Q: Are you a trading company or a physical factory?
A: We are a specialized physical factory for more than 10 years. Our machines also gained CE certificate, ISO9001 and EAC certificate.
Q: What's your main products of your company?
A : We specialized in Vertical Machining Center, CNC Lathe, Milling Machines, Lathes, Drilling Machines, Saws, Shapers and so on.
Q: Can you provide customized machine?
A: Yes, we provide customized service for customers to meet different requirements.
Q: Can we visit your factory?
A: Sure, we warmly welcome you to visit our factory at any time. The more you know about us, the more you will trust us! So you can rest assured on our quality machines and our best service.
Q: What's the Payment Terms ?
A : T/T ,30% deposit when order ,70% balance payment before shipment ; Irrevocable LC at sight.
Q: What is your trade terms?
A: FOB, CIF ,DDP and CFR all acceptable.
>>
