| Model | DGW230AC |
| Frequency[Hz] | 50 60 |
| Voltage[V] | 220,230,240,110/220,115/230,120/240 |
| Output power[Kva] | 2.0 2.2 |
| No-load Welding Voltage[V] | 50~65 |
| Welding Current[A] | 200 |
| Working Welding Voltage[V] | 25~30 |
| Current Adjustment Range[A] | 70 ~ 220 |
| Continuous Welding Load Rate | 60% |
| Phase | Single phase |
| Excitation Method | Brush self-excitation |
| Power Factor Φ | 1 |
| Insulation Class | F |
| Fuel Tank Capacity[L] | 12.5 |
| Engine Model | 192FA |
| Start Method | Electric start |
| Engine Type | single cylinder、4 stroke、air-cooled、vertical |
| Bore*Stroke[mm] | 92 * 75 |
| Displacement[L] | 0.499 |
| Compression Ratio | 19.5：1 |
| Speed | 3000 3600 |
| Power[Kw] | 7.5 8.2 |
| Drive Way | Crankshaft |
| Oil Capacity[L] | 1.65 |
| Fuel No. | Diesel: 0#(Sumner), -10#(Winter) Use No. 0 diesel in summer, and use No. -10 or No. -20 diesel in winter. |
| Oil No. | SAE10W30 (CD grade or above) uses CD or above grade 15W-40 oil (or SAE equivalent grade oil) |
| Size [mm] (L*W*H) | 700*485*600 |
| Packing Size[mm] (L*W*H) | 710*500*620 |
| Net Weight/Gross Weight[Kg] | 123/126 |
