Product Details
Product Description
Product Description
Product Description
FPM double disc refiner is a coarse and fine pulping equipment in the pulping system of paper making industry. It can also be used as a high efficiency dredging equipment for slurry regrinding and waste paper repulping, it has the advantages of high production efficiency and low power consumption.
Item
| FPM380
| FPM450
| FPM550
| FPM600
|
Diameter of grinding disc(mm)
| φ380
| φ450
| φ550
| φ600
|
Production capacity(T/D)
| 6-20
| 8-40
| 25-80
| 40-120
|
Concentration of inflow pulp(%)
| 2-5
| 2-5
| 2-5
| 2-5
|
Pressure of inflow pulp(Mpa)
| 0.1-0.3
| 0.1-0.3
| 0.1-0.3
| 0.1-0.3
|
Diameter of inflow pulp pipe(mm)
| 2-φ65
| 2-φ70
| 2-φ85
| 2-φ90
|
Diameter of output(mm)
| φ70
| φ100
| φ120
| φ150
|
Power of motor(kw)
| 37kw/6level
| 90-110/6level
| 132-160/6level
| 160-250/6level
|
Our Services
Fangyuan Zhonghe has a complete sales service system, which is composed of marketing, distribution management, direct sales business, technical support, after-sales service, regional development and other parts of the network throughout the country. These network nodes form an organic whole with the company headquarters and serve the users wholeheartedly.
Company Information
Fangyuan Zhonghe Machinery Co., Ltd. (formerly Zhucheng Fangyuan Machinery Co., Ltd.) is the backbone enterprise specializing in the production of environmental-friendly pulp and papermaking equipment, tissue paper machine and sewage treatment equipment. The company is next to Qingdao free trade zone Zhucheng functional area. The main products include two categories, more than 50 series, sewage treatment equipment, pulp and papermaking equipment and crescent tissue paper machine. With the high technology content, it has reached the advanced level of the same industry in China.
FAQ
Q1. Are you a manufacturer?
A: Yes, we have been concentrating on this series of products for more than 20 years of experience
Q2. How to install the equipment?
A: We can give you guide by video, voice, email af all kinds chatting APP
If there's still doubt, we can arrange the professinal engineer to install in your country
Q3. How many models does the equipment have?
A: We have FPM-380, FPM-450,FPM-550, etc.
You can choose the model you need according to your parameters.
Q4. How do you pack the products?
A: Normally as the export standard or as your needs
Q5. What is your available port of shipment?
A: Qingdao port, etc.
Q6. Do you offer guarantee for the products?A: Yes, under the right condition, we can offer time warranty for our products
>>
