Z3040 Multi-Functional Mechanical Radial Drilling Machine with High Performance and High Efficiency

Product Description

Product Description
Rocker Arm Drill Product Introduction
The Radial Drilling Machine is a versatile and essential piece of hole-processing equipment, expertly designed for drilling, reaming, tapping, and face trimming, among other processes. Ideally suited for both single and mass production scenarios involving large parts with multiple holes, this machine is a staple in general machining workshops. Its main features include:
Structural Features: The innovative design allows the rocker arm to rotate and lift around the column, while the spindle box moves horizontally along the arm. This exceptional engineering ensures ease of operation, outstanding flexibility, and a wide application range, especially for large and heavy workpieces.
Classification: Radial drilling machines are categorized by their clamping structures into hydraulic and mechanical variants. Furthermore, based on drilling size and mechanical principles, the rocker arm drills are available in various models and specifications to cater to diverse processing needs.
Technical Parameters: The machine's capabilities are defined by its technical parameters, such as maximum drilling diameter, distance from the spindle to the column, the gap from the spindle face to the working table, and spindle rotation speed. These parameters are crucial in determining the machine's efficiency and processing capacity.
Safety Performance: Equipped with comprehensive safety protocols, the radial drilling machine includes a spindle overload protection device, a spindle travel limit switch, and a safety nut on the lifting screw, all aimed at ensuring safe and reliable operation.
Application: This radial drilling machine is indispensable across various machining departments. Its applications span drilling, reaming, countersinking, tapping, and boring, making it a pivotal tool in machining and production settings.
Operation and Maintenance: With options for manual or numerical control operation modes and both mechanical and hydraulic transmission, proper usage and maintenance are vital to sustaining high performance and extending the machine's lifespan.
In summary, the radial drilling machine stands as a highly functional, efficient, and safe hole-processing tool. It perfectly suits the production of diverse metal parts and holds a vital role as indispensable equipment in modern machining workshops.
Product Parameters
Rocker Arm Drill Product Performance
The Radial Drilling Machine is part of a new series of multifunctional products, offering outstanding performance, safety, reliability, and ease of maintenance. It boasts high precision, robust rigidity, and extended longevity. Featuring hydraulic primary variable speed mechanisms, it reduces auxiliary time and simplifies operations with straightforward handle controls. The hydraulic-driven clamping mechanisms on the spindle box, rocker arm, and columns ensure reliable clamping. Enhanced durability is achieved through quenching of the rocker arm guide rail, spindle, and rotating raceway surfaces, maintaining machine accuracy. Moreover, comprehensive safety devices and column protection further guarantee safe operation.
Classified by clamping structure, radial drilling machines come in hydraulic and mechanical types. The hydraulic radial drilling machine, with its ease of operation and broad applicability, is particularly suited for processing large parts with multiple holes, making it a common choice in general machining workshops.

Product Name	Radial drill	Radial drill	Radial drill
Product model	3040*13/16	3032	Z3050*13/16
Maximum diameter of hole	casting40/Steel part35mm	casting32/Steel part27mm	casting50/Steel part45mm
Distance from spindle end face to table	430-1210mm	360-1050mm	360-1300mm
Distance from spindle center to column busbar	300-1100mm	260-1050mm	260-1050mm
Spindle travel	220mm	120mm	220mm
Main shaft hole cone	4Mohs	4Mohs	4Mohs
Spindle speed range	34.78.145..75130.560.260.430.920.380.760.1280rpm		34.78.145..75130.560.260.430.920.380.760.1280rpm
Spindle speed class speed	12	6	12
Spindle feed range	0.10-0.25rpm	0.10-0.25rpm	0.10-0.25rpm
Spindle feed series	3	3	3
Swing arm rotation Angle	Plus or minus 180 degrees	Plus or minus 180 degrees	Plus or minus 180 degrees
motor power	2.2kw	1.5kw	4kw
Machine weight	1400kg	9600kg	2400kg
Overall dimension	1500*705*2020mm	1350*705*1880mm	1950*810*2450mm
