China Remote Control Door Opener

Product Description

TOMA good quality swing gate openers
TM-G12B
Supply voltage: 24VDC, Power of motor: 40W
Current: 3.0A 2.5A, Rotational speed: 3200RPM
Rod's running speed: 1.6cm/s, Rod's max travel: 300mm
Max single-leaf length: 3M, Max single-leaf weight: 300Kg
Environment temperature: -20º C-+55º C, Protection class: IP44
In case of power failure, release the clutch easily, operate the gate manually. Stop acting when gate meets with obstacle
Control box: Power supply: 220VAC 50Hz/110V 60Hz, Transformer: 24V 150W, Accessories max loaded: 24VDC 500mA, Max load: 2× 80W/24VDC, Environment temperature: -20º C-+55º C, Protection fuse: 10A, Running time protection: Adjustable,
Auto closing delay time: Adjustable, Controlling single or double-leaf, Force: Adjustable is optional, Protection class: IP55, 24VDC back-up battery can be input.
TM-G12
WITH LIMIT STOPPER, Supply voltage: 24VDC, Power of motor: 40W
Current: 3.0A 2.5A, Rotational speed: 1500RPM
Rod's running speed: 1.6cm/s, Rod's max travel: 300mm
Max single-leaf length: 3M, Max single-leaf weight: 300Kg
Environment temperature: -20º C-+55º C, Protection class: IP55
In case of power failure, release the clutch easily, operate the gate manually. Stop acting when gate meets with obstacle
Control box:
Power supply: 220VAC 50Hz/110V 60Hz, Transformer: 24V 150W,
Accessories max loaded: 24VDC 500mA,
Max load: 2× 80W/24VDC, Protection fuse: 10A
Running time protection: Adjustable, Auto closing delay time: Adjustable, Controlling single or double-leaf
Force: Adjustable is optional, Protection class: IP55, 24VDC back-up battery can be input.
TM-G27
Voltage: AC 230V/120V
Max single gate weight: 1000KG(weight of gate and length of gate is in a ratio. ) length of motor: 920mm
TM-G320A
Input Voltage: 220V/ 110V
Working Voltage: DC 24V
Ambient Temperature: -50 ~ +100 Celsius degree
Gate Width (single leaf): <= 6M
Gate Weight (single leaf): <= 600kgs
Regular Components: 2 motors, 1 control box, 2 transmitters
Optional Parts: IR sensor, storage battery, visual doorbell, card reader, fingerprint reader

---
