Cheese Tea Nutrition Mushroom Powder Single Double Shaft Substrate Horizontal Ribbon Mixer with Spraying 300 Liter 100 500 Kilo

Product Description

Product Description This two-dimensional motion mixer is mainly composed of three parts: the drum, the swing frame and the frame. The drum is mounted on a swing frame and is supported by four rollers and axially positioned by two retaining wheels. Among the four supporting rollers, two of the driving wheels are dragged by the rotating power system to rotate the rotating cylinder; the swinging frame is driven by a set of crank swinging mechanism, the crank swinging mechanism is mounted on the frame, and the swinging frame is supported by the bearing The assembly is supported on the rack.
Features The drum of the two-dimensional motion mixer can perform two movements at the same time, one for the rotation of the drum and the other for the swing of the drum with the swing frame. The mixture is rotated, inverted, and mixed with the drum in the drum, and the mixing motion of the left and right back and forth occurs with the swing of the drum. Under the joint action of the two movements, the material is fully obtained in a short time. the mix of. The EYH two-dimensional mixer is suitable for the mixing of all powder and granular materials.

Applications This multi-directional motion mixer is a material mixer widely used in pharmaceutical , chemical , metallurgy , food , light industry , agriculture and other industries . The machine can mix powder or granules very evenly to achieve the best results after mixing .
Product Parameters

Model	Barrel Volume (L)	Loading Volume (L)	Maximum Loading Volume (kg/batch)	Oscillating Times (r/min)	Total Power (kw)	Dimension (X×Y×Z×Z1)	Total Weight (kg)	Barrel Weight (kg)
EYH-150	150	90	45	37	1.15	800×1050×1450×1340	190	50
EYH-300	300	180	90	17.5/11	1.3	900×1350×1550×1400	340	60
EYH-600	600	360	180	15/9	3	1150×2050×2000×1850	1150	140
EYH-1000	1000	480	240	11/6.4	3	1300×2010×2150×2000	1600	200
EYH-1500	1500	600	300	8/5.4	3	1300×2200×2000×1800	1700	240
EYH-2000	2000	900	450	8/5	4.4	1500×2250×2150×2000	2000	320
EYH-3000A	3000	1200	600	8.3/4.7	5.2	1660×2750×2255×2120	2600	430
EYH-4000A	4000	1800	900	7/4.5	8	1850×3100×2550×2350	3500	620
EYH-6000A	6000	2400	1200	6.5/3.8	9.5	2010×4300×2760×2570	4100	700
EYH-8000A	8000	3600	1800	5.6/3.1	13	2200×5100×3380×3050	6100	1100
