Factory Price 1000W 1200W 1800W IP66 Ik08 10kv SPD Precision Aiming Device Die-Casting 1-10V Dimmingled Outdoor Stadium Light Floodlight LED Flood Light

Product Description

Factory Price 1000W 1200W 1800W IP66 Ik08 10KV SPD Precision Aiming Device Die-Casting 1-10V Dimming LED Court Light LED Outdoor Stadium Light Floodlight
Quick Detail
World class level chips, high brightness, low light decay & long life-time
International driver brand, overheat protection, high convert efficiency, high PF & surge protection, (1-10V,DALI2.0)
Die-casting technology with ADC12, excellent thermal management and balance the internal & external temperature, reduce chip Tj and light decay.
Optical UV resistant PC lens with 94% light transmitance, IK08. Light Distribution: 10°/15°/25°/45°/60°/90°/Asymmetrical 60°
Bracket Installation, operation temperature: -35C- +50C
Specifications

Model N0.	MF-QCDG-S400w	MF-QCDG-S500w	MF-QCDG-S600w	MF-QCDG-S800w	MF-QCDG-S1000w	MF-QCDG-S1200w	MF-QCDG-S1500w	MF-QCDG-S1800w
lnputVoltage	AC100-277v
output Voltage	DC42
Rated Power	400w	500w	600w	800w	1000w	1200w	1500W	1800W
Qty of LED	840PCS*3030	840PCS*3030	840PCS*3030	168CPCS*3030	1680PCS*3030	168OPCs*3030	2520PCS*3030	2520PCs*3030
PF	>0.95
LED Brand	World class level
Luminous Flux	60000lm±5%	75000lm±5%	90000lm±5%	120000lm±5%	150000lm±5%	180000lm±5%	225000Im5%	270000lm5%
CRI	Ra>80
CCT	3000-6500K
Beam Angle	10/25/45/60/90 Asymmetrical 60°
Driver Brand	MW/SOSEN
THD	<10%
lK Rating	IK08
Rating	IP66
Life Span	50000Hrs
Size	718*214*222mm	718*214*222mm	718*214.222mm	732*439*290mm	732.439*290mm	732*439*290mm	732*666*290mm	732*666*290mm
N.W	19.15kg	19.65kg	20.05kg	32.00kg	33.0Okg	34.0Okg	46.00kg	47.30kg
G.W	21.55kg	22.05kg	22.5skg	35.30kg	36.30kg	37.30kg	49.70kg	51.00kg

Detailed Photos
1.Modular Design: each module has powerrating from 400W to 600W, three modulescan be combined into 1800W
2.Die Casting Heat Sink: concise appearanceexcellent thermal management & compactstructure.
3.Handlebar Design: easy for installation & carry
4.Racked Angle: allows for precise installation, up to 270°
5.High-strength cold-rolled plate design with integral flanging and bending,light weight, high mechanical strength
6.Special Corrosion Treatment: to reach theWF2 standard and suitable for harshenvironments
7.Precision Aiming Device.
8.Tempered Glass Cover: achieve lK08 rating and additional protection to the lens to apply harsh conditions.
9.Spill Light Options: reduces light pollution
10.Double Surge Protection: driver & extra 10KV SPD Photometry

Dimension
Installation Instructions
Vertical Horizontal Suspended Spill Shield Packaging & Shipping
Applications
Roads and highways / Parking lots / Sports stadiums / Railroad yards / Shipyards / Warehouses / Truck stops and rest areas /
Outdoor parks and recreation areas / Playgrounds / Storage facilities
Any Outdoor place,Etc
Here are some examples of versatile LED high mast light applications:
Outdoor sports lighting: LED high mast lights can be used for sports lighting in stadiums, arenas, and outdoor fields, providing bright and uniform lighting for athletes and spectators.
Industrial lighting: LED high mast lights can be used for lighting in industrial settings such as warehouses, manufacturing plants, and construction sites, providing high-quality lighting for workers and equipment.
Airport lighting: LED high mast lights can be used for lighting in airport runways, taxiways, and aprons, providing safe and efficient lighting for pilots and ground crews.
Port lighting: LED high mast lights can be used for lighting in port areas such as loading docks, container yards, and shipyards, providing safe and efficient lighting for workers and equipment.
Highway lighting: LED high mast lights can be used for highway lighting, providing bright and uniform lighting for drivers and reducing the risk of accidents.
Parking lot lighting: LED high mast lights can be used for lighting in parking lots, providing safe and efficient lighting for drivers and pedestrians.
Public area lighting: LED high mast lights can be used for lighting in public areas such as parks, plazas, and pedestrian walkways, providing safe and efficient lighting for pedestrians and enhancing the overall ambiance of the area.
Overall, LED high mast lights are a versatile lighting solution that can be used in a wide range of applications, providing high-quality lighting and enhancing safety and efficiency.

---
