Mini Universal Vertical Milling Machine with CE Certificate Xq6226b Xq6226A Xq6226-1g

Product Description

UNIVERSAL SWIVAL HEAD MILLING MACHINE (XQ6226-1G)
1. Heavy machine frame with wide, adjustable dovetail guides in all axes
2. Rigid universal cutter head, can be moved to virtually any spatial angle
on two levels
3. Automatic table feed on X and Y axes, including rapid feed
4. Motorized height adjustment in Z direction
5. Head can rotate in different angle for using Horizontal arbors
6. spindle speed changed by ram box.
STANDARD ACCESSORIES:
1.Mill chuck
2.Inner hexagon spanner
3.Face mill arbor
4.Nut washer
5.Tool bar
6.Adapter shaft
7.Support
8.Foundation bolt
.Draw bar
10.Wrench
11.Screw
OPTIONAL ACCESSORIES:
1.DRO
2.Clamping kit
3.Rotary worktable
4.Universal dividing Head
5.Machine vice
6.CE
7.New Operation Panel
8.Hanging Operation panel

MODEL	UNIT	XQ6226B	XQ6226A	XQ6226-1G
Table size	mm	1120X260	1120X260	1120X260
T slot	no	3	3	5
Size ( Width )	mm	14	14	14
Centre distance	mm	63	63	50
Max. load of Table	kg	250	250	250
table Longitudinal travel(manual/auto)	mm	600	600	600
table Cross travel (manual/auto)	mm	270	270	270
table Vertical travel(manual/auto)	mm	380	400	400
Spindle taper	/	ISO40	ISO40	ISO40
spindle speed /step	rpm	45-1660/11steps	45-1660/11steps	45-1660/11steps
Max.end milling width	mm	125	125	125
Max. vertical milling Dia.	mm	25	25	25
swivel angle of swivel head	degree	360º	360º	360º
vertical spindle axis to column surface	mm	60-500	60-500	60-500
vertical spindle nose to table surface	mm	100-480	100-480	100-480
arm travel	mm	440	440	440
Longitudinal/cross feed	mm / min	24-402/9steps	24-402/9steps	24-720/8steps
Vertical/step	mm/min	422/1step	/	/
Longitudinal/cross rapid speed	mm / min	402	402	1040(X)
Rapid Traverse vertical	mm/min	422/1step	/	/
main motor	kW	2.2	2.2	2.2
(X/Y/Z) feed motor	kW	0.37(X/Y),0.55(Z)	0.37(X/Y)	0.37(X)
coolant motor	kW	0.04	0.04	0.04
package dimension	cm	160X152X222 1pc/case	160X152X222 1pc/case	160X152X222 1pc/case
overall dimension	cm	166x150x173	166x150x173	166x150x173
N/W,G/W	kg	1480/1680	1400/1600	1300/1450

---
