8-168m Scissor Lift Table Manual Lifting Platform Aluminum Mast Lift Platform Hydraulic

Product Description

Packaging & Delivery
Package Size
150.00cm * 140.00cm * 140.00cm
Package Gross Weight
900.000kg
Product Description
Factory direct sale of various aerial work platforms for sale and rental
Portable scissor lift platform is widely used for aerial working,it has the advantage of self-propelled,small volume,high workingefficiency etc. It has walking and lifting function,with the control handle to control the direction of running,speed can beadjusted,equipped with a brake device,battery driven DC motor running and movements,you can also choose AC motor or diesel enginerunning and movements,it also can use wireless electronic remote control movements,without the need for manual traction and doesnot need an external power supply,flexible and convenient in movement,it is ideal product for aerial working.
Product Description
Recommend machine
Product Parameters

Model No.	YG400	YG600	YG800	YG800A	YG1000	YG1000A	YG1200	YG1400	YG1600
Machine Length(m)	1.47	1.86	2.48	2.48	2.48	2.48	2.48	2.48	2.85
Machine Width(m)	0.76	0.768	1.19	0.83	1.19	0.82	1.19	1.19	1.25
Load(kg)	240	230	450	320	450	230	320	320	230
Max. Platform height(m)	3.9	5.8	6	6	8	8	10	11.8	13.7
Working height(m)	5.8	7.8	8	8	10	10	12	13.8	15.7
Platform extension size(m)	0.6	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9
Platform size(m)	1.34X0.7	1.67X0.74	2.27X1.12	2.27X0.81	2.27X1.12	2.27X0.81	2.27X1.12	2.27X1.12	2.64X1.12
Batteries(V/Ah)	2X12/105	4X6/225	4X6/225	4X6/225	4X6/240	4X6/225	4X6/240	4X12/300	4X12/300
Charger(V/A)	24/15	24/25	24/25	24/25	24/25	24/25	24/25	24/25	24/25
Gradeability	25%	25%	25%	25%	25%	25%	25%	25%	25%
Max.working slope	1.5°/3°	1.5°/3°	1.5°/3°	1.5°/3°	1.5°/3°	1.5°/3°	1.5°/3°	1.5°/3°	1.5°/3°
Overall weight(kg)	890	1460	2170	2090	2360	2260	2640	2980	3600

Detailed Photos

---
