Aluminium Window CNC End Milling Notching Machine

Product Description

Jinan SETH Intelligent Equipment Co.Ltd Product Description
Aluminium window cnc end milling notching machine
Equipment characteristics
☆It is used for milling the end surface of aluminum profile to meet the matching of medium and frame materials
High efficiency milling multiple profiles at one time
☆ five cutting tools, can be processed to strengthen the
☆ tool can be adjusted up and down to fit different shapes and sizes
☆ tool is adjustable and do not need not be customized when processing different profiles, thus reducing production preparation, cycle and cost
A phase-sequence protector is installed in ☆ circuit system to improve the security of the system
A Air-cylinder damping device is used in the ☆ system, which is stable and reliable
Main Specifications and Technical Parameters
☆ input: V 50Hz 380
☆ motor total power: KW 9.4
☆ motor speed: r/min 2800
☆ gas source working pressure: MPa 0.5-0.8
☆ milling cutter spindle diameter :φ32mm
☆ cutter diameter :φ250mm
☆ workstation feed itinerary: mm 0-1560
☆ table size :530×320 mm
☆ motor adjustment stroke: mm 0-85
Maximum ☆ tenon size :40 mm
☆ dimensions :3240×1020×1670
Standard configuration:

Serial number	Name of name	Brand brand	Origin
1	Automatic circuit breaker	S chneider	France
2	Phase Sequence Protector	S chneider	France
3	AC contactor	S chneider	France
4	Thermal Protector	S chneider	France
5	Switching power supply	S chneider	France
6	Relay	S chneider	France
7	Low voltage switch button	S chneider	France
8	Terminal	Honeywell	United States
9	Motor motors	Siemens	Germany
10	Alloy milling cutter	wagen	Japan
11	Lead screw	Hiwin	Taiwan
12	Solenoid valve	Airtac	Taiwan
13	High Flexible Wire Cable	Yongheng	Jiangsu Province
14	Cylinder	Baidi	Shandong Province

Detailed Photos
Company Profile

Jinan SETH intelligent equipment co., ltd. specializes in the production of aluminum,PVC,upvc window and door machine,curtain wall and hollow glass processing machine equipment that can meet the needs of different clients, and can also be customized according to customer requirements of different grades of products.
The company has rich experience in production and more than 10 national patents and passed ISO9001,SGS,CE certifications, excellent product design and development engineers, skilled production engineers, experienced production management team and after-sales service that providing you with a strong guarantee.
The company has all kinds of equipment processing workshop, assembly workshop and quality inspection center, can independently realize the design of equipment, processing, assembly, test one-stop flow operation, to ensure the excellent quality of equipment.
Our main products including aluminum&uPVC profile machining center, saw machine ,milling machine,welding machine,corner cleaning machine.corner crimping machine,punching&drilling machine.
Customer is the foundation, the company in line with the " quality first, customer first" principle, Please join hands with SETH to lead intelligence. Certifications
