Factory Low Price UL Standard Insulation Grade Soft PVC Compounds for Cables

Product Description

Product Description:

This series of PVC compounds is made of PVC resin as the base materials and special plastic additives .It is processed by domestic advanced twin-screw granulator. This product comply with standards of ROHS,PAHS,DEHP,POFS and also can customized REACH standard as customers' request.

Advantage:

Good temperature resistance
Solvent and oil resistance
Smooth and delicate surface
Excellent extrusion processing performance
Environmentally friendly
Comply with ROHS&REACH
UL

Application

Item No	Description					Application
RY-E401601VC	60ºC UL Standard insulation grade soft PVC Compounds					Apply for UL standard wires and cables,such as power cables, electronic wires, computer cables, high voltage cables, headphone wires, automotive wires, instrument wires, electrical equipment wires, etc. The speed can be more than 200M/min for sheath grade and above 800m/min for the insulation grade of the thin-wall wires.
RY-E402602VC	60ºC UL Standard sheath grade soft PVC Compounds
RY-E403901VC	90ºCUL Standard insulation grade soft PVC Compounds
RY-E404902VC	90ºCUL Standard sheath grade soft PVC Compounds
RY-E405051VC	105ºCUL Standard insulation grade soft PVC Compounds
RY-E406052VC	105ºCUL Standard sheath grade soft PVC Compounds
RY-E407051VC	105ºC Environmentally friendly UL standard semi-hard insulation grade PVC Compounds					Apply for 105ºC temperature resistant grade semi-hard communication cables

Technical Properities:

No	Item	Unit	RY-E401601VC	RY-E402602VC	RY-E403901VC	RY-E404902VC	RY-E405051VC	RY-E406052VC	RY-E407051VC
1	Tensile Strength	MPa	≥15	≥15	≥16	≥16	≥16	≥16	≥16
2	Elongation at Break	%	≥180	≥180	≥150	≥150	≥150	≥150	≥150
3	Thermal Deformation	%	≤40	≤40	≤40	≤50	≤40	≤50	≤40
4	Impact Brittleness Temperature	ºC	-15	-20	-15	-20	-15	-20	-15
5	Thermal stability time at 200ºC	min	≥60	≥60	≥80	≥80	≥80	≥80	≥80
6	Volume Resistivity at 20ºC	Ω.m	≥1.0×1011	≥1.0×109	≥1.0×1011	≥1.0×109	≥1.0×1011	≥1.0×109	≥1.0×1012
7	Volume Resistivity at 90ºC	Ω.m	---	---	≥1.0×108	---	≥1.0×108	---	≥1.0×109
8	Dielectric Strength	MV/m	≥20	≥20	≥20	≥20	≥20	≥20	≥20
9	Thermal Aging Performance(UL Oven)	ºC×Day	100×7	100×7	121×7	121×7	136×7	136×7	136×7
	Retention Rate of Tensile Strength after Aging	%	≥75	≥75	≥75	≥75	≥75	≥75	≥75
	Retention Rate of Elongation at Break after Aging	%	≥75	≥75	≥75	≥75	≥75	≥75	≥75
10	Oxygen Index	%	Customized	Customized	Customized	Customized	Customized	Customized	Customized
11	Remark		Pass VM-1	Pass VM-1	Pass VM-1	Pass VM-1	Pass VM-1	Pass VM-1	Pass VM-1

Package, Transportation and Storage

Package: 25kg per bag, inner PE film and outer kraft paper bag and pallets
Transportation and Storage: Cable materials should not be exposed to the sun and rain during transportation. They should be stored in a clean, cool, dry and ventilated warehouse and also should be handled and carried gently. The shelf life is 6 months.
Ten pallets for a 20'FCL

Company Profile

We,Suzhou Ruiyang Plastic Technology Co., Ltd is a professional manufacturer with 10 years experience in the cable materials in China. We mainly manufacture and supply a series of PVC, LSZH cable materials, special wires &cables materials and cross skeleton etc., which are widely apply for all kinds of cables,such as the communication cables with CMX, CM, CMR, CMP grades ,automotive wires which meet the international standards of the US, Japan, France, and as well as the CL standard of Volkswagen and Porsche and so on. Our company has passed the ISO 9001:2000 quality management system certification . All our products can meet the compliance of ROHS and REACH .The current production capacity is about 2,000,000 kilograms per year.
We own a strong technical research and development team, adhering to the development concept
of "scientific and technological innovation, quality first, customer first" which go all out to
provide customers with good solutions from beginning to end.
We have own IM/EX right, our products with high quality and competitive prices.

Workshop

Test Equipments

Certificate& Test reports

FAQ

1. Are you trading company or Manufacturer ?
We are a professional manufacturer. We are warmly welcome clients from worldwide to visit our factory and cooperate with us.
2.What can you buy from us?
PVC Granules,LSZH granules,Polyethylene,HDPE Granules,LDPE Granules,Cross skeleton, Nucleating agent and other Plastic Granules.
3.Why choose us?
We are a professional manufacturer .We can offer very competitive prices and high quality for all our products.
4.Do you provide samples ? Is it free or extra ?
Yes, We can offer samples below 25kgs, but customers have to bear the shipping cost.
5.How long is your delivery time?
5-10 days. Only when the quantity exceeds 10000kgs delivery time will be agreed by negotiations.
6.Do you accept customization?
Yes,All products can be customized for different requirements.
7.What are your payment terms ?
We'd like to use T/T as the terms of payment. L/C terms can be communicated.

---
