Aluminum Clad Titanium Steel Bimetallic Composite Plate Sheet Transition Joints

Product Description

Aluminum Clad Titanium Steel Bimetallic Composite Plate Sheet Transition Joints
Aluminum has excellent electrical conductivity and thermal conductivity, making it widely used in the electrical industry. Aluminum is non-ferromagnetic, which is an important characteristic for the electrical industry and the electronics industry.
The specific strength of some aluminum alloys is comparable to that of steel, and its specific stiffness exceeds that of steel. Therefore, aluminum alloy materials have been widely used in transportation, chemical industry, machinery, power, electronics and construction, especially in aerospace industry.
The temperature of the joint is usually <300ºC. If titanium is added between aluminum and steel, both aluminum titanium steel bimetallic bimetal transition joints are used, the bonding strength and conductivity can remain unchanged when the service temperature reaches 450 ºC.

Base plate alloy	Q235,Q245R,Q345R,DH36,CCSB
Middle plate alloy	TA1,TA2
Cladding plate alloy	5083, 1060,1070
Standard	CB 1343-98
Cladding plate thickness	≥10mm
Base plate thickness	≥12mm
Length	≤3000mm
Width	≥20mm

Usage:
1. Aluminum-titanium stainless steel pipe joints are used for the transition connection between the components of large-scale cold mills and the pipes conveying liquid nitrogen and liquid oxygen.
2.Aluminum Clad Titanium Steel Bimetallic Composite Plate Sheet Transition Joints used in ship structure construction.
3. Titanium acts as the intermediate layer in the multi-layer composite plate which replaces the flange connection in the cryogenic device, such as the corrosion-resistant aluminum alloy-pure aluminum-titanium-nickel-stainless steel composite plate.

---
