| US$16.00-60.00 | 5 Pieces (MOQ) |
| Conversion principle | E-AA/D | Function description | • 2-A high-precision analog-to-digital conversion, can handle-16-18 MV range of signals No need to re-calibration, high precision, good consistency • The A9P has a built-in stylus • DC interface with anti-reverse connection, anti-short circuit protection Anti-interference ability, wide use of the environment • AC/DC dual-purpose, standard battery • 7-bit 0.8-inch LED display, 3 battery indicator • The zero tracking range and the zerosetting (boot/manual) range can be set separately • It has two-point linear correction function and two compensation calibration methods • Large storage capacity, can store 1001 sets of weighing records, 1000 sets of car number and weight, 201 sets of goods number can print horizontal and vertical weight sheet, can print a variety of statistical statements • Equipped with RS232 communication port (RS422/RS485 is optional) , current ring large screen communication port, standard parallel printing port and thermal micro-printer |
| Conversion speed | 10 times/sec | ||
| A/D conversion resolution | A million yards | ||
| Input Range | -16mv~18mv | ||
| Division | 1/2/5/10/2/50/100 (selectable) | ||
| Sensor connection | Using 6-wire type, long line automatic compensation | ||
| Clock | Display Year/month/day, hour/minute/ second, automatic leap year, leap month | ||
| Bridge supply | DC, 10V, can Be connected to 8 3500 or 16 7000 sensors | ||
| Large screen display interface | Transmission Mode: 200MA current loop | ||
| Baud rate | 600 | ||
| Transmission Distance | <2000m | ||
| Transmission Mode | RS232C/RS422(optional)/ RS485 (optional) | ||
| Baud rate | 600/1200/2400/4800/9600(selectable) | ||
| Transmission Distance | RS232<30m; RS422/RS485 <1200m | ||
| Print interface | • Standard parallel output interface • Data Storage: can store 1000 vehicle number and truck weight, 201 goods number and 1001 group weighing record • Direct current supply: DC 6V/10AH storage battery (external) |
