US$0.325
305-3,049 Meters
US$0.18
3,050-5,999 Meters
Basic Info.
Application
Widely Used in Home Appliance ,Lighting Heater etc
Conductor Material
Tinned Copper Wire
Insulation Material
Silicone
Material Shape
Round Wire
Range of Application
Widely Used in Home Appliance ,Light ,Heater,Motor
Certification
ISO9001, CE, CCC, RoHS, VDE
Capacity
300,000km Annual
Colorized
Accept Customized
Conductor Construction
420/0.25
Transport Package
Coil or Spool Packing with Carton
Production Capacity
2000000meters Per Day
Packaging & Delivery
Package Size
50.00cm * 50.00cm * 50.00cm
Package Gross Weight
2.100kg
Product Description
Product Parameters UL3213 Specification:
Certificate :ROHS, CCC,UL ,CUL ,VDE,CE
GB/T19001, ISO9001
Rated temperature:150 C
Rated voltage:600V
Conductor :solid or stranded wire (2~8AWG) of tin-plated or bare copper wire .
Insulator:silicone Rubber
Braided material:Silicone rubber
Color ::red \blue \white \yellow \green \brown \black
Application areas:Insulated protective wire of Electronic Appliances,lighting equipments, Industrial Machinery and heated products.
We can make all kinds of special specification silicone wires and braided silicone wires to customer's order.
| Conductor | Insulation | Max.Cond Resistance | Unit length |
Size
(AWG) | Construction
(No./mm) | Diameter
(mm) | Nominal Thickness
(mm) | Diameter
(mm) | (Ω/KM) | (M)(Ft) |
| 8 | 19/0.75 | 3.75 | 1.55 | 6.85 | 2.16 | 100/328 |
| 6 | 266/0.254 | 5.52 | 1.55 | 8.62 | 1.362 | 100/328 |
| 4 | 420/0.254 | 6.63 | 1.55 | 9.73 | 0.8559 | 100/328 |
| 2 | 655/0.254 | 8.75 | 1.55 | 11.85 | 0.5384 | 100/328 |
