Wire Braided Flexible High Pressure Hydraulic Rubber Hose 2sn, Above 200, 000 Impulse Cycles

US$0.60-10.00 1,000 Meters (MOQ)

Basic Info.

Model NO.
hydraulic hose
Color
Black
Model
R2
Length
20m, 40m, 60m or as Your Request
Hose I.D.
3/16′′~2"
Reinforcement
Two Braided Layer of High Tensile Steel Wire
Temperature Range
-40°c to 120°c
Surface Option
Smooth or Cloth Wrapped Surface
Applications
Construction, Machine Tool and Agriculture
Transport Package
Shipping
Specification
3/16′′-2′′
Trademark
UGW
Origin
China

Product Description

EN853 2SN SAE100 R2 AT hydraulic rubber hose
Inner tube: Nitrile
Reinforcement: Two braid of high-tensile steel wire
Cover: Black Neoprene Blend
Temperature Range: -40°F to 212°F(-40ºCto 100ºC)
Application standards: EN853 2SN,GB3683.1 2SN,SAE J517 R1S, ISO 1436 2SN
Branding: 2SN-16-25mm 1''GB /T3683.1 SAE J517 EN853 W.P. 8.8Mpa(2390psi)

Application:
High-pressure hydraulic oil lines used in construction, machine tool and agriculture application using petroleum or water -based hydraulic fluids. Hose sizes 3/16-5/8''have a vacuum rating of 28 in Hg. Hose size3/4''-1''have a vacuum rating of 24 in Hg.
SAE 100 R2 technical data
Items number Hose I.D. Hose O.D. Max W.P. Min B.P Min.B.R Weight
in mm Mpa psi Mpa psi mm Kg/m
2SN-3 3/16 14.1 41.5 6019 165 23930 90 0.27
2SN-4 1/4 15.7 40.0 5801 160 23204 100 0.34
2SN-5 5/16 17.3 35.0 5076 140 20304 115 0.39
2SN-6 3/8 19.7 33.0 4786 132 19144 130 0.49
2SN-8 1/2 23.0 27.5 3989 110 15956 180 0.59
2SN-10 5/8 26.2 25.0 3625 100 14500 200 0.71
2SN-12 3/4 30.1 21.5 3118 86 12472 240 0.89
2SN-16 1 38.9 16.5 2393 65 9430 300 1.37
2SN-20 1 1/4 49.5 12.5 1813 50 7252 420 2.27
2SN-24 1 1/2 55.9 9.0 1305 36 5220 500 2.44
2SN-32 2 68.6 8.0 1160 32 4640 630 3.00

Quality control:
Our Lab:
Packaging & Shipment: Paper+pallet/carton box+pallet/roll package
Application: Construction machinery
Our Services 1. We can offer OEM Services
2. We can provide FREE SAMPLE for our customers
3. We can crimp hose assembly for our customers.
4. We welcome clients to visit our factory leading to a better understanding of our production.
