1000kg Plastic HDPE Recycling Crusher Machine

Product Description

1000kg plastic hdpe recycling crusher machine ,is mainly used to crush plastic film ,pipe, like HDPE film ,PP woven bag, PE pipe, PVC pipe, PET bottle and on one, the min. size can be 12mm, so we can do up to custoner require size. The capacity can be from 500kg to 2000kg/h.

Project summary
NO.	Item	Specification
1	Material	Plastic/PET bottle,PP/PE hard plastic.PP/PE film and so on
2	Capacity	Capacity:500-2000kg/h according to your material
3	Final products size	<16mm or customerized
4	Electricity power supply	380V 50HZ 3Phase or customized
5	Water supply	The buyer supply the water connection pipes
6	Others:	Germany technology,automatic overload protect,high efficiency,best knife material,thickness steel,low noise ect
Note:The material output you can choose use the blower and silo or use the screw conveyor,the bottom is as the picture of below

Advance of our crusher machine
1. Spindle Rotor:
Spindle rotor adopt steel structure with high strength, unique V-design. Also can design the most suitable spindle according to different materials. And the spindle use strict static and dynamic balance test to ensure smooth and reliable machine operation.
2. External bearing housings
Housing installed outside of main body, adopt wool felt seal between the spindle and the box. Effectively prevent the crushed material into the bearing box, improve bearing life.
3. Opening and closing device by hydraulic
Upper and down crushing room, screen bracket, the use of hydraulic control automatic opening and closing. Facilitate machine maintenance, blade, screen replacement, the rapid completion of crushing cabinet clean.
4. Blade changing fixed protection device
Blade changing process can keep fixed spindle rotor, cut the circuit, easy to tighten the fastening bolts. To prevent operation of the machine, do not operate to protect the safety of maintenance personnel.
Motor pohoes of the machine
In side of the crusher
If you need more detail of the machine kindly feel free to contact me, I can send you more photoes and vedio, we also can make desig for you up to your raw material 1. We supply below necessary documents with the machine:
Machine layout Electricity diagram Machine certificate General manual book/maintenance book 2. We provides one-year quality guarantee. During this period, if the machine's malfunction is approved to be our responsibility, we will send the broken spare parts to you with DHL courier or other way within 7 workdays after receiving the complainant. And send the technicians to the buyer's factory for maintaining. All charges are in our account.
3. After one year guarantee, If you need we can provides payable spare parts and technician's VISITING maintenance, and any broken spares we can send you soon as possible.
4. We trust that our quotation meets with your requirements and we will gladly furnish you with further information.
5. 24Hours service : Cell+86-13915707468

---
