| Frequency range | TX/RX | 8.33 kHz spacing 118.000-136,992 MHz 25kHz spacing 118.000-136.975 MHz | |
| RX Wx Channels | 161.650-163.275MHz(USA only) | ||
| Number of memory channels | 240 ch (Max.) | ||
| Channel spacing | 8.33 kHz/25 kHz | ||
| Power supply requirements | 13.8/27.5vDC (automatic selectlon) | ||
| current drain | TX | 5.0A Max. | |
| RX | Stand-by | 500 mA | |
| Max. audio | 4.0A | ||
| Dimensions (WHxD) (Projections are not included) | 160x×34x271 mm 6.3×1.34x10.67in | ||
| Weight | 1.0 kg;2.2 lb | ||
| operating temperature range | -20°C to +55°C | ||
| Frequency stability | ±5ppm | ||
