ASME B16.20 Metal Rx Ring Joint Gasket for Optimal Sealing

Product Description

Product Description Introducing the Xinsen-J Ring Joint Gasket
The Premium Ring Joint Gasket Our product is expertly crafted as a versatile sealing gasket available in numerous configurations, meticulously processed from premium solid metals. Manufactured using a variety of high-grade materials, they undergo precise and meticulous mechanical cutting with cutting-edge CNC lathes. These gaskets are distinguished by a compact installation profile and deliver outstanding high pretension pressure, making them perfect for sealing components in pressure vessels, valves, and cylinders. They are specifically engineered to excel under conditions of extreme temperatures, high pressures, and severe corrosiveness, ensuring dependable and robust performance.
Gasket Types:
High-Quality Flat Gasket Durable Oval Ring Joint Gasket Precision Octagonal Ring Joint Gasket Robust RX Metal Gasket Superior BX Metal Gasket Optional Materials:

Materials	Code	Hardness HB	Temperature(ºC)
Soft iron	SI	90	530
Carbon steel	CS	120	530
304 (L), 321, 316 (L)	S304, S321, S316	160	750
5Cr1/2Mo	F5	130	500
INCONEL	INC	160	1000

Detailed Photos

---
