| US$4.80-28.00 | 1 Piece (MOQ) |
| TSK6510 | TSK6520 | TSK6540 | TSK6560 | TSK6580 | TSK6590 | |
| Frequency | 125KHz/13.56Mhz | |||||
| Supporting Card | EM4100 card serial number ,ISO/IEC14443A/B, ISO15693 & ISO18092 | |||||
| Read Distance | > 8cm(Depending on label sizeand surroundings) | |||||
| Interface | Wiegand26/34,RS232,RS485,A BA (TVS transient pulse protection) | |||||
| Power Supply | DC9V ~ 12V | |||||
| Current | <50mA | |||||
| Working Distance | >100m(Using the national standard Cat5e network cable, test results without interference) | |||||
| Protection Level | IP65 epoxy resin embedment | |||||
| Operating Temperature | -10ºC ~ 70ºC | |||||
| Storage Temperature | -20ºC ~ 80ºC | |||||
| Humidity | 0 ~ 95% | |||||
| Dimension | 111*70*14mm | 80*43*13mm | 118*76*22mm | 105*47*23mm | 122*75*20mm | 122*45*20mm |
| 125Khz /ISO7815 | EM4100 / H4100/ EM4200/ TK4100/EM4102 / H4102/EM4105/EM4305/EM4450/ATA5577/Hitag2/Hitag S 256 |
| ISO / IEC 14443 A ,ISO / IEC 14443 B &ISO / IEC 15693 | M 1K S50 / MF1 S50,M 4K S70 / MF1 S70,M Plus S2K,M Plus S4K,Ntag203,Ultralight,Ultralight c,DesFire EV1 8K(MF3 IC D81),DesFire 4K (MF3 IC D40),DesFire EV1 4K (MF3 IC D41),SRI512,I.code SLI SI2 / I.code 2,I.code SLI-S,I.code SLI-L,Tag-IT Ti2048,Tag-IT Ti256 |
