Wp Woodworking Bench Grinder Solid Wood Thickness Jointer Machine Thickness Planer Press

Product Description

Wood Planner-Woodworking Flat Press Planer:
Motor: (induction motor) Input 2800W, Output 2200W, 440V
Planing: maximum cutting width of 304mm
Maximum cutting thickness 3mm
Pressure planing: minimum wood thickness 3mm
Maximum wood thickness 220mm
Maximum wood width 300mm
Maximum cutting depth 3mm
Feed speed: infinitely variable speed
Knife shaft: Knife shaft speed 5500RPM
4 straight knives (high-speed steel)
Rounded spiral knife: 6 slots, 56 pieces (imported blade)
Straight blade size: 305 * 25 * 3mm
Cutting diameter of tool shaft: 78mm
Workbench: Flat planing 1510 * 304mm
Pressure planing 588 * 310mm
The height of the flat plane above the ground is 901mm
Guide rail: size 1100 * 165mm
Angles 90-135 degrees
Moving method: round rod guide rail
Features: Independently variable feed speed for planing; Mechanical digital display for the lifting and lowering of the planing handwheel; 4 directional adjustable casters for easy movement; The flat plane and pressure plane have independent vacuum ports, which have good vacuum effect
Overall dimension: 1600 * 1050 * 1150mm
Packaging size: 1650 * 650 * 1150mm
Net weight/gross weight: 280KG/320KG

Motor	Input 2800W, Output 2200W, 440V	maximum cutting width	304mm
Maximum cutting thickness	3mm	minimum wood thickness	3mm
Maximum wood thickness	220mm	Maximum wood width	300mm
Maximum cutting depth	3mm	Knife shaft speed	5500RPM
Straight blade size	305 * 25 * 3mm	Cutting diameter of tool shaft	78mm
Flat planing	1510 * 304mm	Pressure planing	588 * 310mm
height of the flat plane above the ground	901mm	Guide rail	1100 * 165mm
Angles	90-135 degrees	Overall dimension	1600 * 1050 * 1150mm
Net weight/gross weight	280KG/320KG	Rounded spiral knife	6 slots, 56 pieces (imported blade)

Guangzhou Yamu Paile Industry & Trade Co., Ltd. (WOODPLAYER)

Specializes in manufacturing woodworking machine, include bandsaw machine, table saw machine, wood milling machine, wood lathe, wood sander machine, CNC router and wood dust collector. also we supply all kinds of these machine's parts, and relative product, crafts etc.
Our factory is devoted to the research and development of woodworking machine. "woodplayer" branded woodworking machine have obtained remarkable achievements in the design of precise carving machine technologies.
Our machines are sold in many European and American countries. These products are very popular in these markets and have established a leading position in the woodworking machine market.
After several years of rapid development, our woodworking machines have already covered advertisement in decoration, woodworking, cabinet furniture crafts wood toys fields. Our machine well meet the demands of customers in different countries and regions.
We keep trying our best to produce innovative products to help customers lower their costs and increase their returns. If you are interested in our products, please no hesitate to contact us for future cooperation. We hope to get mutual benefits with you in the near future.
