Metal Profile Shutter Door Rolling Machine

Product Description

rolling shutter door forming machine
1. Components:
1. Decoiler
2. Coil sheet guiding and adjusting equipment
3. Film covered device(optional)
4. Main roll forming system
5. Hydraulic pump station
6. PLC control system
7. Cutting device
8. Run-out table

2. Work flow:
Decoiling the sheet----sheet guilding----film covering(option)----roll forming----PLC controlling----hydraulic cutting----receiving the finished panel

3. Technical Parameters:

No.	Main parameter for rolling shutter door forming machine
1	Suitable to process	Galvanized/Aluminum/Color steel sheet
2	Width of plate	1250mm
3	Thickness of plate	0.3-0.8mm
4	Rollers	High grade 45# steel, with hard chrome plating
5	Forming steps	16
6	Sprocket chain	1.5 inch
7	Pump station power	4kw
8	Shaft	75mm, high grade 45# steel, heat treatment
9	Hydraulic oil pump	CB-E310
10	Weight	About 5.0 tons
11	Productivity	8-12m/min
12	Cutting head	Cr12 mould steel with quenched treatment
13	Control system	TAIDA brand PLC control
14	Voltage	380V 3Phase 60Hz
15	Motor power	4kw
16	Dimension	About 6.8m*1.5m*1.5m
17	Hydraulic pressure	10-12mpa
18	Index error of length	±1mm
19	The temperature range of working line	-35-50°

Above all the parameters can be changed exactly according to customer's requirements.
4. Advantage of DIXIN roll forming machine

No.	DIXIN roll forming machine
1	High grade quality
2	Reasonable price
3	High efficiency
4	Low failure rate
5	Low energy consumption
6	Free after-sale service
7	Reliable working
8	Durable
9	Wide application
10	Beautiful appearance
11	Welcomed by all over the world customers
12	Professional foreign trade team
13	Mature technician team
14	Customize special type

5. Want a free quotation for make budget?
Just send inquiry to me now!
6. We are your reliable partner!
We always do the best to make our machine perfect in every detail part.
Any pics or videos about machine, we can provide you.
7. Payment terms
30% T/T as the deposit when contract signed, 70% balanced before shipping.
Our services:
1. we can produce the special machine,send your drawing to us,we can design for you.
2. if you buy our products,we also can help you to purchase the material,like color roll,the price is lower than you buy by yourself.
3. we provide a one year warranty and lifelong technical support, we can send our technicians to you to give you on-site training.
The training period would be for no more than one week with the customer paying for the visa, return ticket, food, accommodations and a daily wage of US80.
4. engineers available to service machinery overseas.
5. if you come to visit our factory,we can book the room for you, car pick up to send.
Company Introduce
Our enterprise, Cangzhou Dixin Roll Forming Machine Co., Ltd, as the professional and leading manufacturer, can manufacture, design, installation and debug various roll forming machines and metal processing sheet equipments, which produce metal roof wall panel, glazed roof tile, CZ steel purlin, floor decking, roof ridge cap, sandwich panel, roof truss, shutter panel, shutter slat, door frame, guardrail, and metal sheet uncoiler, bending, slitting, cutting, flattening, punching, crimping.
Backed by reasonable design, precision machining and selected material, both our standard and customized machines are characterized by long life span, precise forming and easy operation. With our customers' trust, our machines have been sent to America, Australia, Russia, India, Sri Lanka, Nigeria, Pakistan, Uzbekistan, Mozambique, Angola, Turkey, Brazil, etc. We can satisfy the different needs of different markets.
Warmly welcome to China to visit our factory and select the machines you need. Our address,Fuzhuang Industrial Development Zone, Botou City, Hebei Province, China.

Any questions, we will reply to you promptly.
