Wumu Fullly Open Shedding Textile Electronic Jacquard Machine Wmz-L Series for Water Jet Loom

US$6,000.00-20,000.00 1 Set (MOQ)

Basic Info.

Model NO.
WMZ-L
Computerized
Computerized
Precision
High Precision
Certification
CE, ISO9001: 2000
Warranty
1 Year
Customized
Customized
Condition
New
After-sales Service
Available
Hooks
1024,1408,1792,2816
Loading
Ningbo/Shanghai
Speed
Upto 250 Rpm
Transport Package
Pallet
Specification
1000*1000*1000
Trademark
WUMU Tech
Origin
China
HS Code
8448
Production Capacity
200 Set/Month

Packaging & Delivery

Package Size
300.00cm * 100.00cm * 190.00cm
Package Gross Weight
2000.000kg

Product Description


· PRODUCT INTRODUCTION--------------------------------------------------------- Type:WMZ1024L,WMZ1408L,WMZ1792L,WMZ2816L Speed: Upto 250RPM Selection Method: Module + drive circuit board + aluminum alloy lifting knife Shedding Form: Double-lift,fully-open shedding Shedding Height: The front shedding width range is 55-97mm. Back shedding width range is 97-120mm with easy adjustment. Driving Mode:Vertical shaft + gear box / Customized Servo or Motor Note: Other specification can be made according to customers' requirement. CHARACTERISTICS-------------------------------------------------------------------------------- This high quality electronic jacquard machine is designed specially for heavy duty designs or high speed looms. Driving system is optimized and improved which makes the machine running in stable and low noise to make good use of shedding height. Power consumption will decrease when it runs in heavy duty designs by using module selection. Embedded intelligent control module and touch-screen human-computer interaction interface has better experience. It can meet the requirement of running in high-speed and long term. Customized servo or motor runs in no vertical shaft but synchrodrive with looms. RANGE OF APPLICATION--------------------------------------------------------------------------- Matching with shuttle looms and medium and low speed rapier looms. Suitable for weaving label,saree, towel, shawl etc. TECHNOLOGY PARAMETER
TYPE Length A (mm) Width B (mm) Height C (mm) Weight (kg)
WMZ1024L 745 1029 892 298
WMZ1408L 902 1029 892 310
WMZ1792L 1076 1029 997 575
WMZ2816L 1444 1029 892 632

MACHINE'S PHOTO
