0.5-26mm Electrical Cable Core Wire Making Conductor Winding Extrude Extrusion Machine

US$58,000.00 1 Set (MOQ)

Basic Info.

Model NO.
FC-50+35/70+40/90+45
Plastic Processed
Polystyrene
Product Type
Profile Extrusion Molding Machine
Feeding Mode
Multiple Feed
Assembly Structure
Integral Type Extruder
Screw
Single-Screw
Automation
Automatic
Computerized
Computerized
High Temperatrue
280 Degree
Usage
Applied FEP,Fpa,ETFE Fluorine Plastic′s Production
Cylinder Diameter
Diameter65mm
Revoling Speed of Screw
60rpm
Extrusion Output
45kg/H
Power for Main Machine
22kw
Pay off Type
Dynamic or Tension Wire Feeding
Evacuating Device
Vacuum Generator
Pre-Heater
5kVA
Diameter Size Meter
Manual/Laser Automatic Diameter Size Meter
Transport Package
Simply Packed
Specification
ISO
Trademark
Fuchuan
Origin
China
HS Code
847720900
Production Capacity
20PCS/Month

Product Description


φ70+φ35 high speed extrusion machine(Touch screen operation) It is mainly for PVC plastic material extrusion for electric wire and cable wire. Operation direction:right hand machine Main machine center height 1000mm; Inlet wire:φ0.6-φ3.2mm;flat wire also make;(according to mould); Finished wire:φ1.5-φ5.0mm; Production linear speed:350m/min Main machine color:main machine Ral5015 sky blue;electric cabinet: computer white;safe color:yellow. Machine composition High speed automobile wire,electrical wire,power cords and jacket sheathing extrude line
Equipment type 50+30 60+35 70+35 80+45 90+50 100 120
Pay off type 500-630active/barrel pay off 800-1250-2500active pay off
Screw dia 50 60 70 80 90 100 120
L/D ratio 26:1 26:1 26:1 25:1 25:1 25:1 25:1
Glue output 60 90 160 240 280 450 650
Main power 15 22 37 45 55 75 132
Wire size 0.6-3.5 0.8-4 1.0-5.0 1.5-8 6.0-25 6.0-35 20-80
Cooling device Double layer U type Single layer U type
Max accululator length 300 300 300 300
Hauling power 3.7 3.7 5.5 5.5 7.5 7.5 15
Linear speed 0-500 0-800 0-800 0-1000 0-200 0-200 0-80
Take up type 1246automatic coiler,500-800drum take up,cone disc precision take up,630semi-auto dual shaftless take ups 800-1250-2500take up
