Three Phase Power Regulator Thyristor PA400X-I-4-200-C-N-Ng Automatic Voltage Regulator

Product Description

Product Description China PA400X Three Phase display power regulator

Model code
PA400X-	3-phase voltage regulator board (with overcurrent protection and current limiting function)
Input signal	I-	4-20MADC Input impedance: 120Ω
	V-	0-5VDC internal resistance ≥10K
Load connection method		2-	Star neutral point connected to zero line
		3-	The neutral point of triangle or star is not connected to the zero line
		4-	Inner triangle
Rated current			60-	60A
			80-	80A
			100-	100A
			150-	150A
			200-	200A
			250-	250A
			300-	300A
			400-	400A
			500-	500A
			600-	600A
			800-	800A
Trigger method				0-	Phase shift voltage regulation type
				C-	Variable cycle zero-crossing power regulation
				I-	Phase-shift voltage regulation and variable cycle zero-crossing power regulation
Communication Mode					N-	none
					5-	RS485 Communication
External manual function						N	none
						M	With potentiometer
Fast fuse							N	none
							G	With fuse

Order example:PA400X-I-3-50-0-N-NG
PA400X Series Power Regulator,Input signal 4-20MA,Working voltage 380VAC,Rated current 50A,Voltage regulating type, with fast fuse. Our Advantages
PAX400X Series 3-Phase Display Power Regulator
Features
* Phase angle or variable period power, with display function
* Fully controlled circuit, suitable for inductive loads (transformers, silicon-molybdenum rods, silicon-carbon rods)
* Current capacity: 60-800A
* Power supply: 380VAC, frequency 50HZ
* Operating environment: temperature -10ºC-50ºC, humidity ≤90%HR
* Adjustment output range: (0-98%) US, US (power supply voltage)
* Insulation resistance: minimum 20MΩ, 1000VDC
* Support communication: RS485 communication Detailed Photos

Company Profile
Beijing Fuanshi Technology Co., Ltd. is a high-tech enterprise focusing on the fields of industrial intelligent temperature control and semiconductor furnaces.We focus on the research, development, production and sales of industrial intelligent temperature control system products and semiconductor furnace heaters. Our main products include power regulators, thyristor power supplies, temperature control instruments, etc., which have obvious advantages of high efficiency, low heat generation and low film. The products are exported to Europe, America, Southeast Asia and other regions. At the same time, it is an agent for SHINADEN. The company provides users with high-quality services from installation to commissioning in the field of industrial temperature control. The company's engineering technology is updated and rich, and the quality of semiconductor furnace products is reliable and the performance is stable. It has won a good reputation in the glass fiber, semiconductor and other industries. The company adheres to the concept of "talent investment, R&D priority", and is committed to continuously developing new products, expanding the market with high-quality products and services, meeting customer needs, and continuously enhancing brand influence. We look forward to cooperating with you!
Packaging & Shipping
FAQ Q1.Can you provide price sheet and catalog to me ?We are pleasure to provide these to you for reference,you can cotact me,give me your emails ID.
Q2.Can I get some samples?
Yes,Sample order is available for quality check and market test .but you need to pay the sample fee and shipping cost
Q3.How long is your lead time?2-3 days for the stocks items, mass production generally needed 1-2 weeks.
Q4.What's your payment terms?
We usually accept all kinds of payment terms.Such as T/T,L/C,Western Union.Cash.
Q5.What's your warranty terms?
We offer 12 months warranty time.
Q6.Do you have the products in stock?
Depends on your request,We have standard models in stock.Some special products and big order will be newly produced according to your order.
Q7 How about your payment and shipment?Payment: We accept T/T, Western Union, Paypal, Cash etc.We usually ship via DHL, UPS, FedEx or TNT, SF for small order and via ocean for bulk order according to your requirement.
Q8.How does your factory do the quality control?
Quality is priority,we always attach the importance to quality control from the beginning to the end of the production.every product will be fully assembled and carefully tested before packing and shipping.

---
